Introduction

FEATURES:

• Converts digital audio formats
• Both Optical and Coaxial digital outputs work concurrently
regardless of input type selected
• Supports sample rates 32 kHz, 44.1 kHz, 48 kHz, 96 kHz and
192 kHz up to 24-bit resolution
Front Panel
Coaxial
Optical
Select
1
Audio input selector (switch between Optical and Coaxial digital
1
inputs
Optical digital input
2
Coaxial digital input
3
contact
support@blustream.co.uk / support@blustream.com.au
The DIG11AU is a digital audio converter that converts either Optical or Digital coaxial
audio to concurrent Optical and Coaxial Digital outputs.
The DIG11AU is useful for either home or professional audio application.
3
Input
Optical Coaxial
2
• Plug-and-play
• Small compact size
Back Panel
Output
Coaxial
4
Coaxial digital output
4
Optical digital output
5
Power port – Use supplied 5v / 1amp DC adaptor
6
DIG11AU USER MANUAL
5
DIG11AU
Optical DC5V
6
03
