Summary of Contents for turbofan E931M
- Page 1 30MSERIES E 9 3 1 M I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l 234404-6...
- Page 2 MANUFACTURED BY Moffat Limited Christchurch New Zealand INTERNATIONAL CONTACTS AUSTRALIA Moffat Pty Limited Web: www.moffat.com.au E.Mail: vsales@moffat.com.au Main Office: (tel) +61 (03) 9518 3888 (fax) +61 (03) 9518 3833 Service: (tel): 1800 622 216 Spares: (tel): 1800 337 963 Customer Service: (tel): 1800 335 315 (fax): 1800 350 281...
-
Page 3: Table Of Contents
Contents List E931M Turbofan Range. Introduction......................2 Safety Information Specifications......................3 Installation ......................4 Installation Requirements Unpacking Location Clearances Electrical Connection Positioning and Levelling of Range Initial Start-Up Commissioning Operation ........................ 6 Operation Guide Control Panel Using the Cooktop Using the Oven Using the Oven - Grill Function Cleaning ........................ -
Page 4: Introduction
If you are unsure of any aspect of the installation, instructions or performance of your range, contact your Dealer: TURBOFAN dealer promptly. In many cases a phone call could answer your question. Should you contact your TURBOFAN dealer on any matter... -
Page 5: Specifications
Specifications E931M Important: This appliance requires two separate single phase electrical supplies for the Oven and Cooktop. Oven - The oven is supplied with a 3 pin cordset fitted ready to plug in. Cooktop - The Cooktop requires a separate single phase supply connected to the unit. -
Page 6: Installation
It is most important that this range is installed correctly and that range operation is correct before use. If you have any questions regarding the proper installation and / or operation of this range, please contact your local Turbofan distributor. Unpacking Clearances 1. -
Page 7: Positioning And Levelling Of Range
Installation Cooktop: Positioning and Levelling of Range 1. Correctly locate the range into its final operating NOTE: All electrical connections must only be carried position and using a spirit level, adjust the range feet out by a suitably qualified person. so that the range is level and at the correct height. -
Page 8: Operation
Turbofan Ranges have been designed to provide simple operation. This range is intended for use in a commercial kitchen and must only be put to the use for which it was intended, i.e. -
Page 9: Using The Cooktop
Operation Cooling Fan Using the Oven An automatic cooling fan is integrated into the range to Caution maintain correct operating conditions for the appliance. Some parts of this oven will become VERY The cooling fan, when operating, ventilates air from HOT during use and could cause burns if touched accidentally. -
Page 10: Cleaning
Cleaning Cleaning Guidelines b. Partially undo the rack securing screw (anti- clockwise) securing side rack to the range wall, until the rack is loose. Caution c. Pull side racks forward to disengage the location pins at the rear of rack from the rear wall of the Always turn electrical... -
Page 11: Cooktop Cleaning
Cleaning Door Seal Door Glass Cleaning a. To remove door seal, pull the one piece seal Ensure that the range door is cool before cleaning forward until it pulls out of the location groove the range door glass. around the oven. Note the way the seal is fitted to the oven, with the lip facing inwards. -
Page 12: Fault Finding
Fault Finding This section provides a reference to the more common You may encounter a problem not covered in this section, problems that may occur during the operation of your please contact your service provider who will require the oven. This fault finding guide is intended to help you following information:- correct and accurately diagnose problems with your oven. - Page 13 Fault Finding Oven Fault Finding (cont.d): Fault Possible Causes Remedy Oven light not illuminating Oven hot. Blown bulb. Replace bulb. Oven cold. Oven ‘On / Off’, Bake Temperature and Call for service. Grill Control Knob switch faulty. Overtemp tripped (No lights, no power Call for service.
-
Page 14: Electrical Schematics
Electrical Schematics Electrical Schematic E931M Turbofan Range... -
Page 15: Replacement Parts List
For further information and servicing instructions, contact your nearest authorized service provider or Turbofan Dealer. When ordering replacement parts, please quote the part number and the description as listed below. If the part required is not listed below, request the part by description and quote model number and serial number which is shown on the Technical Data Plate. -
Page 16: Appendix 1 - Reversing The Oven Door
Appendix 1 - Reversing the Oven Door Reversing the Oven Door 11. Remove inner glass latching studs and fit to opposite NOTE: side of door using Loctite 243 to secure. Refit all screw fasteners using a low-mid strength thread locking adhesive unless otherwise stated. Remove Latching Studs ... - Page 17 Appendix 1 - Reversing the Oven Door 18. Remove Blanking Screw and Door Catch from front of Adjust Door for Correct Alignment. range and swap around (refer ‘Adjusting Door Catch’). Check alignment and operation of the door. Ensure that the door is correctly aligned horizontally and vertically. Door Catch Blanking Screw 1.
