  • Page 1 30DSERIES E 3 1 D 4 ( D i g i t a l O p e r a t i o n ) I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l 234144-9...
  • Page 2 MANUFACTURED BY Moffat Limited Christchurch New Zealand INTERNATIONAL CONTACTS AUSTRALIA Moffat Pty Limited Web: www.moffat.com.au E.Mail: vsales@moffat.com.au Main Office: (tel) +61 (03) 9518 3888 (fax) +61 (03) 9518 3833 Service: (tel): 1800 622 216 Spares: (tel): 1800 337 963 Customer Service: (tel): 1800 335 315 (fax): 1800 350 281...

  • Page 3: Table Of Contents

    Contents List E31 Turbofan Convection Oven. Model Numbers Covered in this Manual E31D4 - Turbofan Oven - 4 Tray Convection Oven. Introduction ......................2 Safety Information Specifications ......................3 Installation ......................4 Installation Requirements Unpacking Location Clearances Stand Mounted Ovens...

  • Page 4: Introduction

    If you are unsure of any aspect of the installation, Dealer: instructions or performance of your oven, contact your TURBOFAN dealer promptly. In many cases a phone call could answer your question. Service Provider: Should you contact your TURBOFAN dealer on any matter concerning this oven, please have the information provided opposite, readily available.

  • Page 5: Specifications

    Specifications E31D4 Oven Tray Details Oven Power Ratings Tray Capacity Tray Spacing 208V, 1P+N+E, 50/60HZ, 2.9 kW 4 x GN 1/1 Pan 220V, 1P+N+E, 50/60HZ, 3.1 kW 80 mm / 3⅛” 4 x US ½ Pan 230-240V, 1P+N+E, 50/60HZ, 3.1 kW...

  • Page 6: Installation

    It is most important that this oven is installed correctly and that oven operation is correct before use. • If you have any questions regarding the proper installation and / or operation of this oven, please contact your local Turbofan distributor. Clearances Unpacking To ensure correct ventilation for the motor and controls, 1.

  • Page 7: Electrical Connection

    Installation Electrical Connection Warning This oven must be earthed / grounded. If the supply cord is damaged, it must be replaced by a suitably qualified person in order to avoid a hazard. Each oven should be connected to an adequately protected power supply and an isolation switch mounted adjacent to, but not behind the oven and must be readily accessible to the operator.

  • Page 8: Operation

    • Turbofan Ovens have been designed to provide simple operation. • This oven is intended for use in a commercial kitchen and must only be put to the use for which it was intended, i.e.

  • Page 9: Using The Oven - Manual Mode

    Operation Using the Oven - Manual Mode To check actual oven temperature during preheat or cooking, press TURN ‘ON’. ‘Temperature’ button. Actual temperature will display briefly on Press ‘On-Off’ button. ‘Temperature Display’ before the display reverts to the pre-set temperature. Temperature Dislay.

  • Page 10: Cooking In Program Mode

    Operation Cooking in Program Mode TURN ‘ON’. Press ‘On-Off’ button. Press ‘Programs’ button. Program Mode Indicator Heating ‘On’ Temperature Dislay. Indicator Temperature Display will show program selected. To check actual oven temperature during preheat or cooking, press SELECT A PROGRAM ‘Temperature’...

  • Page 11: Setting The Oven Programs

    Operation Setting the Oven Programs Oven can be pre-programmed with up to 20 Program’s. When you receive your oven, the controller is not programmed. To set programs, carry out the following for each program required:- ENTER PROGRAMMING MODE. Press ‘Programs’ button to enter ‘Programming’...

  • Page 12: Operator Accessible Parameters

    Operator Accessible Parameters Setting the Operator Accessible Parameters With the Oven in ‘Stand-By’ mode:- ENTER THE OPERATOR PARAMETER MODE. Press 'Grill / Broil' and 'Start / Stop' buttons together. ‘Temperature’ Display will show ‘PAS’. The ‘Time’ Display will flash. SET PASSWORD Rotate ‘Timer Control’...

  • Page 13: Cleaning And Maintenance

    Cleaning and Maintenance Cleaning Guidelines c. Pull side racks forward to disengage the location pins at the rear of rack from the rear wall of the oven and remove the racks from the oven. Caution d. Clean all racks with a mild anti bacterial detergent and hot water, using a soft bristled brush.

  • Page 14: Periodic Maintenance

    Cleaning and Maintenance Door Seal Door Glass Cleaning a. To remove door seal, pull the 1 piece seal forward • Ensure that the oven door is cool before cleaning until it pulls out of the location groove around the the oven door glass. oven.

  • Page 15: Fault Finding

    Fault Finding This section provides a reference to the more common You may encounter a problem not covered in this section, problems that may occur during the operation of your please contact your service provider who will require the oven. This fault finding guide is intended to help you following information:- correct and accurately diagnose problems with your oven.

  • Page 16: Electrical Schematics

    Electrical Schematics Electrical Schematic E31D4 Turbofan Oven...

  • Page 17: Replacement Parts List

    For further information and servicing instructions, contact your nearest authorized service provider or Turbofan Dealer. When ordering replacement parts, please quote the part number and the description as listed below. If the part required is not listed below, request the part by description and quote model number and serial number which is shown on the Technical Data Plate.

  • Page 18: Appendix 1 - Reversing The Oven Door

    Appendix 1 - Oven Door Reversal Reversing the Oven Door 11. Remove inner glass latching studs and fit to opposite • Refit all screw fasteners using a low-mid strength side of door using Loctite thread locking adhesive unless otherwise stated. 243 to secure.
  • Page 19 Appendix 1 - Oven Door Reversal 18. Remove Blanking Screw and Door Catch from front of Adjust Door for Correct Alignment. oven and swap around (refer ‘Adjusting Door Catch’). Check alignment and operation of the door. Ensure that the door is correctly aligned horizontally and vertically. Door Catch Blanking Screw 1.
