Hardware Installations and Upgrades
Removing the Front Video and USB Module
1. Disconnect video and USB cables from server board (see letter A).
2. Remove the two screws as shown (see letter B).
3. Slide the module out (see letter C).
4. Remove the two screws as shown, slide the front USB header out (see letter D).
Figure 78. Removing the front video and USB Module
®
Intel
Server System R2000LH2/LT2 Service Guide
53
