42" Mower Deck - Housing Group
REF NO PART NO.
0010 1736504BNYP
0020 7301165BZYP
0030 1733577ASM
0040 7301172BZYP
0050 7301170BZYP
0060 1750457BZYP
0070 1750458BZYP
0080 1731402ASM
0090 1931333SM
0100 1731403ASM
0110 1732258BMYP
0120 7301171BZYP
0130 2108765SM
0140 1960170SM
0150 1714760SM
0160 1960687SM
0170 1931277SM
0180 7091524YP
0190 690539E701MA
0200 1931338SM
0210 1935048SM
0220 1919381SM
Footnotes
QTY. DESCRIPTION
1 HOUSING, Mower 42"
1 BRACKET, Rear Support Deck, LH
1 BRACE, Mower Support
1 BRACKET, Rear Support Deck, RH
1 BRACKET, Front Deck
1 PLATE, Spindle, RH
1 PLATE, Spindle, LH
1 SUPPORT, Gauge Wheel R.H. Front
21 CARRIAGE BOLT, 5/16-18 x 3/4 G5
1 SUPPORT, Gauge Wheel, Rear, Left
1 BRACKET, Gauge Wheel, Front, Left
1 BRACKET, Rear Wheel Gauge, RH
4 BOLT, Wheel, 3/8-16 x 2.781
4 WASHER, 1/2" Flat (0.51 ID x 1.00 OD x .10 Thick) Black
4 WHEEL, 2" WIDE, 3.92 DIA
4 NUT, Hex Flange ESNA, 3/8-16
22 NUT, Hex Flange Whiz Lock Small, 5/16-18
4 SCREW, 5/16-18 x 1-1/4" Hex Washer Head Self-Tap
2 BRACKET, Suspension
1 BOLT, 5/16-18 x 1-3/4" Round Head Short Square Neck, GR5
1 NUT, Hex Flange Two Way Locking, 5/16-18
1 WASHER, 5/16" Flat (.341 ID x 1.00 OD x .13 Thick) Black
PTS - 35
CRAFTSMAN ZTS7000 - C950-60106-0
