42" Deck Lift Group - Electric Height of Cut
REF NO PART NO.
1 7091304SM
2 7301104BMYP
3 7103956YP
4 7091584SM
5 7301105BMYP
6 7091619SM
7 009X54MA
8 7090122YP
9 7091503SM
10 7090072SM
11 7091603SM
12 578309MA
13 7301119BCYP
14 7023649YP
15 7301120BMYP
16 164X34MA
17 7090673SM
18 7400011BMYP
19 7026196SM
20 7301125BMYP
21 7091495SM
22 1668344SM
23 7103818YP
24 1734217SM
25 1916950SM
26 1731894SM
27 1666294SM
28 1960687SM
29 094067MA
30 7301098BMYP
31 015X98MA
32 1732129SM
33 7091601SM
34 7300028BMYP
35 7091811SM
36 1960170SM
37 1736081YP
38 1913744SM
39 1737417YP
40 1960379SM
41 1930644SM
42 7301097BMYP
43 1734141SM
44 7027168SM
45 7091593SM
Footnotes
QTY. DESCRIPTION
4 SCREW, 3/8-16 x 1" Hex Head Cap, GR 5, YZ
1 BRACKET, Lift, Deck, Primary
1 ROD, Indicator, Height-Of-Cut
1 NUT, 1/4-20 Hex Flange Lock, GR 5, YZ
1 BRACKET, Lift, Deck, Secondary
4 NUT, 3/8-16 Hex Flange lock, YZ
1 SHOULDER BOLT, 1/4-20 x 3/8"
2 WASHER, 3/8" Flat (SAE)
7 HAIR PIN, 3/32 x 1-1/2" YZ
2 SCREW, 1/4-20 x 5/8" Hex Head Cap, GR 5
4 NUT, 1/4-20 Hex Nyloc, YZ
1 CLEVIS PIN, .25 x 1.09
1 LEVER, Indicator, Height-Of-Cut
1 WASHER, 5/16" Nylon
1 BRACKET, Indicator, Height-Of-Cut
1 SPRING, Compression
1 COTTER PIN, .06 x 1/2" YZ
1 WELDMENT, Deck Lift, 38/42
1 BEARING, Flange, .75 ID PM
1 SPACER, Bearing, .25"
2 SCREW, 1/4-20 x 3/4" Hex Head Cap, GR 5 YZ
1 SHEAR PIN, .248 ID x 1-3/4" Long
1 MOTOR, Actuator, Lift, Deck
2 ROD, Mower Lift (3/8-16 thread) Yellow
2 NUT, 3/8-16 Hex, Black
2 TRUNNION, Powdered Metal, Yellow, Regent
2 SPACER, .385 ID x .6697 OD x .455 Long, PM Yellow
2 NUT, 3/8-16 Hex Flange Esna, Black
2 PIN, 3/8-16 Threaded Shoulder
2 BAR, Rear Lift
4 NUT, 3/8-16 Hex Flange Center Lock, Zinc Plated
2 SHOULDER BOLT, 3/8-16 x .94, BZ
4 NUT, 5/16-18 Flange Lock, YZ
2 BRACKET, Deck Hanger
4 BOLT, 5/16-18 x 5/8" Hex Flange lock, GR 5, YZ
4 WASHER, 1/2" Flat (0.51 ID x 1.00 OD x .10 Thick) Black
2 ROD, Front Bail (1/2-13 thread) MWR
2 NUT, 1/2-13 Hex Jam, Black
2 TRUNNION, Unthreaded
2 NUT, 1/2-13 Jam, Esna Light Thin
2 NUT, 1/2-13 Hex Flange Two-Way Lock Black
1 SUPPORT, Hanger
1 SWITCH, Rocker Electric Height-Of-Cut
2 CAPSCREW, Hex Head, 5/16-18 x 1
2 COTTER PIN, 3/8" Self Lock
PTS - 23
CRAFTSMAN ZTS7000 - C950-60106-0
