Craftsman Remote Controller Operator's Manual page 35

Frame Assembly
REF NO PART NO.
1 7301073BNYP
2 7300140BNYP
3 7090799SM
4 7091086YP
5 7301110BMYP
6 1931211SM
7 7091601SM
8 7091298YP
9 017X47MA
10 7027168SM
11 7091541SM
12 7091894SM
13 7044760SM
14 7400208BMYP
15 7200034SM
16 7091587SM
17 7091218SM
18 7091305SM
19 7100103SM
20 7090122YP
21 7091585SM
22 7103830YP
23 7014048YP
Footnotes
QTY. DESCRIPTION
1 FRAME, RZT
1 FOOTREST
2 BOLT, 5/16-18 x 5/8" Round Head Short Square Neck Carriage, GR 5
1 SCREW, 3/8-16 x 3/4" Hex Head Cap, GR 5 ZP
1 BRACKET, Support, Fuel Tank
1 NUT, 3/8-16 Hex Flange lock, GR F, BZ
2 NUT, 5/16-18, Hex Flange Lock, GR 5
1 NUT, 5/16-18- Nyloc, YZ
1 WASHER, .34 x .62 x 16 Ga, Flat
1 SCREW, 5/16-18 x 1" Hex Head Cap, GR 5, YZ
4 SCREW, 5/16-18 x 3/4" Hex Washer Self-Tap, YZ
1 NUT, 1/2-13 Hex Center Lock, GR 5, YZ
1 SPRING, Torsion, RH Wind
1 WELDMENT, Hydro Idler MY08
1 SPACER, Hydro Idler
1 WASHER, .531 x 1.062 x .121, Flat, YZ (SAE)
1 SCREW, 1/2-13 x 2-1/2", Hex Head Cap, GR 5 (Black Phosphate)
1 SCREW, 3/8-16 x 2" Hex Head Cap, GR 5, YZ
1 IDLER, 3.25" OD x .391 ID x 1.63, Backside
1 WASHER, 3/8" Flat (SAE)
1 NUT, 3/8-16 Hex Center Lock, YZ
1 MAT, Floor Pan, RZT
2 FOOT PAD, Wide
PTS - 3
CRAFTSMAN ZTS7000 - C950-60106-0
