40220, 40221
ASSIGNING ZONES
To assign a zone number to a control unit, do as follows:
With the control unit turned on:
1.
Press the key at the bottom twice for one second, until AUDIO is displayed.
2.
Press the key at the bottom again briefly and pass
MISCELL.
3.
Press the key on the right-hand side of the display ( ).
4.
Press the bottom of the screen repeatedly until you reach ADJUSTM. and
keep ( ) pressed for a few seconds. You will be in the ADJUSTMENT menu.
5.
Use the lower button to navigate to SETUP.
Press the ( ) button for a few seconds and navigate with the right and
left-hand side of the control unit until you see the number of the desired
zone on screen. Then press ( ) for a few seconds.
The number on screen will stop flashing. You have now assigned the
chosen zone to this control unit.
6.
On doing this, all the control units in the installation will adopt SETUP
mode and will automatically register a higher number in their display (if
your control is, for example zone 10, the rest will display 11).
On pressing ( ) for 3 seconds, the rest of the controls in the installation,
except those already programmed will move to 13 (in the example).
Continue in this manner until all the control units in the installation have
zones assigned to them.
NOTE:
You can revert to the main menu at any time by pressing the upper part
of the display twice.
control unit
From the Central unit:
If your installation has a Central unit with a menu option (Central units refs. 40020, 40040 and 40060)
you can initialise Installation set up from this unit.
Consult the central unit manual to proceed with this operation.
AUDIO until you reach
RESETTING ZONE ASSIGNMENT IN THE SYSTEM
If you wish to carry out the SETUP again, you will have to reset the installation (from the control unit), to
do this, follow the procedure from the control unit that is connected:
1.
2.
3.
4.
5.
25
m i s c e l l
S E T U P
nd
2
st
1
Press the key at the bottom twice for one second, until AUDIO is displayed.
Press the bottom part briefly and pass AUDIO until you reach MISCELL.
Press the key on the right-hand side of the display ( ).
Press the bottom of the screen repeatedly until you reach ADJUSTM and keep ( ) pressed for a few seconds.
You will be in the ADJUSTMENT menu.
Use the lower button to navigate to SETUP.
Press the ( ) button for a few seconds and navigate with the right and left-hand side of the control unit
until you see RESET on the screen (between zone 50 and 1).
Then, press key ( ) again for a prolonged period and you will observe after approx. 3 seconds that the
word RESET stops flashing and changes to SETUP 1 in all the installation control units.
S E T U P
7
nd
st
2
1
1
st
1
www.egiaudio.com
nd
2
st
