Step 3.Install Camera and Network Devices
The Outdoor Bullet camera can either be connected to a PoE-enabled switch or a non-PoE switch.
I.
If using a PoE-enabled switch:
1)
Use a single Ethernet cable to connect the camera to the PoE-enabled switch.
II.
If using a non-PoE switch:
1)
Use a standard RJ-45 cable to connect the camera to a PoE Injector.
2)
Use a standard RJ-45 cable to connect the PoE Injector to the non-PoE switch.
III. Use a standard power cable to connect the PoE Injector to a power outlet. If using a PoE
injector as power input (For GOB-100A, WOB-100A):
1)
Use a standard RJ-45 cable to connect the camera to a PoE Injector.
2)
Use a standard power cable to connect the PoE Injector to a power outlet.
7
