Invacare Perfecto2IRC5PO2AW Service Manual page 69

SECTION 20—4-WAY VALVE/MANIFOLD ASSEMBLY
Manifold
DETAIL "A"
Opening
O-Ring
Air Flow Passage
Exploded View
Assembled View
NOTE: DO NOT disassemble.
Spade Connectors attach here
Locknut
(Leave Wire Connectors Intact)
Coil
Valve
Pilot Valve Stem
Slotted
Pilot Valve
Poppet
Yoke
Stem
Tapered
Valve
End
New
Label
O-Ring
Manifold
FIGURE 20.2 Replacing Pilot Valve Poppets and O-Rings
69
Part No 1154245 Perfecto ™
2
