User Manual
Oxygen Concentrators without SensO
Perfecto
Model IRC5PO2
Model IRC5PO2W
Model IRC5PO2V
Dealer: This manual MUST be given to the end
user of this product.
User: BEFORE using this product, read this
manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com
Perfecto
Oxygen Concentrators with SensO
HomeFill
with SensO
2
Series
™
2
Compatible
®
2
®,
2
2
Perfecto
2
Model IRC5P
Model IRC5PW
Advertisement
Table of Contents
Related Manuals for Invacare Perfecto2 IRC5PO2
Summary of Contents for Invacare Perfecto2 IRC5PO2
- Page 1 Model IRC5PO2V Dealer: This manual MUST be given to the end user of this product. User: BEFORE using this product, read this manual and save for future reference. For more information regarding Invacare products, parts, and services, please visit www.invacare.com...
-
Page 2: Accessories
Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. ACCESSORIES There are many different types of humidifiers, oxygen tubing, cannulas and masks that can be used with this device. -
Page 3: Table Of Contents
Table of Contents TABLE OF CONTENTS ACCESSORIES ..........2 SPECIAL NOTES ..........4 LABEL LOCATION ..........6 SECTION 1—GENERAL GUIDELINES .....7 To Reduce the Risk of Burns, Electrocution, Fire or Injury to Persons ....................7 Operating Information ............... 8 Radio Frequency Interference............8 SECTION 2—FEATURES ........10 SECTION 3—HANDLING ........11 Unpacking.................... -
Page 4: Special Notes
SPECIAL NOTES SPECIAL NOTES Signal words are used in this manual and apply to hazards or unsafe practices which could result in personal injury or property damage. Refer to the following table for definitions of the signal words. SIGNAL WORD MEANING Danger indicates an imminently hazardous situation DANGER... - Page 5 State in which he/she practices to use or order the use of this device.” Invacare recommends an alternate source of supplemental oxygen in the event of a power outage, alarm condition or mechanical failure. Consult your physician or equipment provider for the type of reserve system required.
-
Page 6: Label Location
LABEL LOCATION LABEL LOCATION CAUTION Federal (USA) law restricts this device to sale by or on the order of a physician. Serial Number Label is located on the resonator intake assembly Specification Label is located on the back near the bottom Perfecto Series Part No 1143482... -
Page 7: Section 1-General Guidelines
These substances MUST be kept away from the oxygen concentrator, tubing and connections, and all other oxygen equipment. DO NOT use any lubricants unless recommended by Invacare. Avoid creation of any spark near medical oxygen equipment. This includes sparks from static electricity created by any type of friction. -
Page 8: Operating Information
SECTION 1—GENERAL GUIDELINES Operating Information For optimum performance, Invacare recommends that each concentrator be on and running for a minimum of 30 minutes at a time. Shorter periods of operation may reduce maximum product life. Keep the oxygen tubing, cord, and unit out from under such... - Page 9 SECTION 1—GENERAL GUIDELINES Other devices may experience interference from even the low levels of electromagnetic emissions permitted by the above standards. To determine if the emissions from the Perfecto causing the interference, turn the Perfecto Off. If the interference with the other device(s) stops, then the Perfecto is causing the interference.
-
Page 10: Section 2-Features
When not in use, the plug provided with the concentrator should be inserted into the outlet fitting. For more information about Power *Outlet the HomeFill, contact your Invacare Cord Fitting dealer. Perfecto Series Part No 1143482... -
Page 11: Section 3-Handling
The concentrator should ALWAYS be kept in the upright position to prevent cabinet damage while being transported. If the concentrator is to be reshipped by common carrier, additional cartons are available from Invacare. Unpacking NOTE: For this procedure, refer to FIGURE 3.1. -
Page 12: Section 4-Typical Product Parameters
5 psi ± 0.5 psi (34.5 kPa ± 3.45 kPa) Flow Range: 0.5 to 5 L/min For flowrates less than 1 L/min, we recommend the use of the Invacare Pediatric Flowmeter IRCPF16 Accessory. Potential Obstruction Alert: 0 L/min to 0.5 L/min... - Page 13 SECTION 4—TYPICAL PRODUCT PARAMETERS Safety System: Current overload or line surge shutdown. High temperature compressor shutdown. High Pressure Alarm w/compressor shutdown. Low Pressure Alarm w/compressor shutdown. Battery Free Power Loss Alarm. SensO Oxygen System Possible Obstruction Alert. Width: 15 in ± 3/8 in (38.1 cm ± 1 cm) Height: 23 in ±...
-
Page 14: Section 5-Operating Instructions
SECTION 5—OPERATING INSTRUCTIONS OPERATING SECTION 5— INSTRUCTIONS Introduction Your oxygen concentrator is intended for individual use indoors. It is an electronically operated device that separates oxygen from room air. It provides high concentration of oxygen directly to you through a nasal cannula. Clinical studies have documented that oxygen concentrators are therapeutically equivalent to other types of oxygen delivery systems. -
Page 15: Set Up
SECTION 5—OPERATING INSTRUCTIONS Set Up Plug in Power Cord Plug in power cord to an electrical outlet. Connect Humidifier (If So Prescribed) WARNING DO NOT overfill humidifier. DO NOT reverse the oxygen input and output connections. Water from the humidifier bottle will travel through the cannula back to the patient. - Page 16 SECTION 5—OPERATING INSTRUCTIONS Humidifier Bottle Adapter Insert Flat Head Screwdriver Here Cabinet Filter Filter Access Door FIGURE 5.2 Humidifer Bottle Adapter 5. Attach the humidifier bottle adapter to the humidifier bottle by turning the wing nut on the humidifier bottle counterclockwise until it is securely fastened.
-
Page 17: Power Switch
SECTION 5—OPERATING INSTRUCTIONS Oxygen Outlet DETAIL “A” DETAIL “B” Connector Oxygen Humidifier Tubing Bottle Humidifier Adapter Bottle Outlet Humidifier Bottle Humidifier Bottle Humidifier Compartment FIGURE 5.3 Humidifier Compartment Power Switch NOTE: For this procedure, refer to FIGURE 5.4. 1. Press power switch to on position. -
Page 18: Flowrate
SECTION 5—OPERATING INSTRUCTIONS Flowrate NOTE: For this procedure, refer to FIGURE 5.5 on page 19. 1. Turn the flowrate knob to the setting prescribed by your physician or therapist. CAUTION Never set the flow greater than 5 L/min. WARNING DO NOT change the L/min setting on the flowmeter unless a change has been prescribed by your physician or therapist. - Page 19 SECTION 5—OPERATING INSTRUCTIONS Flow Knob Flowmeter 0.5 L/min Ball Front Panel FIGURE 5.5 Flowrate Front Panel Indicators - Units with SensO The SensO feature monitors the purity of oxygen generated by the oxygen concentrator. If purity falls below factory preset standards, indicator lights on the control panel will illuminate.
- Page 20 SECTION 5—OPERATING INSTRUCTIONS Initial Startup of the Concentrator NOTE: Concentrator may be used during the initial start warm-up time (approximately 30 min.) while waiting for the O purity to reach maximum. LABEL PURITY INDICATOR LIGHTS (LED) SYMBOL SYSTEM OKAY GREEN Indicator Light over 85% Between 73% to 85% YELLOW Indicator light A.
-
Page 21: Initial Startup Of The Concentrator
SECTION 5—OPERATING INSTRUCTIONS Initial Startup of the Concentrator NOTE: Concentrator may be used during the initial start warm-up time (approximately 30 min). O purity will build to a maximum during this period. LABEL STATUS INDICATOR LIGHTS SYMBOL (LED) SYSTEM OKAY GREEN Indicator Light SYSTEM FAILURE RED Indicator light... -
Page 22: Section 6-Maintenance
SECTION 6—MAINTENANCE SECTION 6—MAINTENANCE WARNING The Invacare concentrators are specifically designed to minimize routine preventive maintenance. Only qualified personnel should perform preventive maintenance on the concentrator. Unplug the concentrator when cleaning. To avoid electrical shock, DO NOT remove cabinet. NOTE: At a minimum, preventive maintenance MUST be performed according to the maintenance record guidelines. -
Page 23: Cleaning The Cabinet
SECTION 6—MAINTENANCE FIGURE 6.1 Cleaning the Cabinet Filter Cleaning the Cabinet Clean the cabinet with a mild household cleaner and non-abrasive cloth or sponge. Cleaning the Humidifier NOTE: To clean the oxygen humidifier, follow the instructions provided by the manufacturer. If none are provided, follow these STEPS: 1. - Page 24 SECTION 6—MAINTENANCE MODEL NO. IR C SERIAL NO. FIGURE 6.2 Preventive Maintenance Record Perfecto Series Part No 1143482 ™...
-
Page 25: Section 7-Troubleshooting Guide
SECTION 7—TROUBLESHOOTING GUIDE SECTION 7—TROUBLESHOOTING GUIDE SYMPTOM: PROBABLE CAUSE: SOLUTION: Alarm: Main Power Loss: 1. Insert plug into outlet. Short beeps, long 1. Power cord not pause plugged in. 2. No power at outlet. 2. Inspect house circuit Concentrator not breakers or fuses. - Page 26 SECTION 7—TROUBLESHOOTING GUIDE SYMPTOM: PROBABLE CAUSE: SOLUTION: 2. Flowmeter set at 0.5 2. Reset flowmeter to L/min or less. prescribed flowrate. If prescribed flowrate is below 0.5 L/min, use the Pediatric Flowmeter IRCPF16 (Only with Perfecto NOTE: The use of the pediatric flowmeter will deactivate the Potential Obstruction Alert.
-
Page 27: Limited Warranty
Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty. - Page 28 CONTAINED HEREIN. THE APPLICATION OF ANY IMPLIED WARRANTY WHATSOEVER SHALL NOT EXTEND BEYOND THE DURATION OF THE EXPRESS WARRANTY PROVIDED HEREIN. INVACARE SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES WHATSOEVER. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION...
