SECTION 6—PREVENTIVE MAINTENANCE
12. Reinstall cabinet. Refer to Removing Cabinet on page 22.
Top of Manifold
Exhaust Tube
Sound Box
Rubber Grommet
Tie Wraps
Throttling Muffler
Exhaust Canister
DETAIL "A"
Muffler Body
8" Tie-Wrap
Throttling
Muffler
Exhaust Muffler
Assembly
Muffler Grommet
Grommet
Exhaust
Canister
8" Tie-Wrap
FIGURE 6.5 Replacing the Muffler Assembly
