FEATURES

FEATURES
FRONT VIEW
Oxygen Purity Indicator
Oxygen Outlet
Lights / Fault and Power
Indicator Lights (SensO
2
Model Only)
Flowmeter
Circuit Breaker
Power Switch
Hour
Meter
ACCESSORIES (NOT SHOWN):
PreciseR ™ Pediatric Flowmeter Accessory - IRCPF16AW
X
HomeFill home oxygen compressor - IOH200AW
*NOTE: This outlet fitting is to be used only
for filling oxygen cylinders with the HomeFill
home oxygen compressor. The outlet fitting
does not affect concentrator performance.
Refer to the HomeFill owner's manual, part
number 1145804 - Northern, 1145805 -
Southern, 1145806 - Scandinavian, for
connection and operating instructions. When
not in use, the plug provided with the
concentrator should be inserted into the outlet
fitting. For more information about the
HomeFill, contact your Invacare dealer.
Outlet Fitting*
Power Inlet
6
Perfecto ™ Part No 1154245
2
