Program Edit P4

Here, you can make volume-related settings.
There are two independent amps, and the signals which are input to each amp are determined by the
setting of "3-2a: Routing" ( page 47 of this manual).
4–1: Amp
4–1a
4–1b
4–1c
4–1d
4–1e
4–1a: Amp 1
Amplitude
Specifies the volume level of amp 1. The input signal to amp 1 is determined by the "3-2a:Routing" setting
EG (Amplitude Modulation EG)
Selects the EG that will create time-variant change in the volume level of amp 1. For the settings of each EG,
refer to "Program Edit P5."
AMS (Alternate Modulation Source)
Selects a modulation source ( page 64 of this manual) that will control the volume level of amp 1.
Intensity (Amplitude AMS Intensity)
Specifies the depth and direction of the effect of "AMS" on the volume level.
4–1b: Keyboard Track (Amplitude 1 Keyboard Track)
Low Key
Specifies the key at which Lower keyboard tracking will begin.
High Key
Specifies the key at which Higher keyboard tracking will begin.
Low Int.
Specifies the way in which keyboard tracking will affect the volume of notes below the Low Key.
[0...99]
[EG1...EG4, Amp EG]
[OFF...MIDI (CC#83)]
[–99...+99]
[C-1...G9]
[C-1...G9]
[–99...+99]
