1–3: OSC 1 Pitch
Here, you can make settings for the basic pitch of oscillator 1, pitch modulation, and pitch slope.
1–3a
1–3b
1–3c
1–3a: Basic Pitch
Specifies the basic pitch of oscillator 1
Octave
Specifies the basic pitch of oscillator 1 in steps of an octave. 32' is two octaves below, 16' is one octave below, 8'
is standard pitch, and 4' is one octave above.
Transpose
Adjusts the basic pitch specified by "Octave" in semitone steps.
Tune
Makes fine adjustments to the pitch in one-cent steps.
Frequency Ofs
Makes fine adjustments to the pitch in 0.1 Hz steps.
1–3b: Pitch Modulation
Specifies the pitch Modulation.
AMS.1 (Alternate Modulation Source 1)
Selects a modulation source 1 ( page 64 of this manual) which will modify the pitch (e.g., apply vibrato).
Intensity (Pitch AMS.1 Intensity)
Specifies the depth and direction of the pitch change that will be controlled by "AMS.1."
AMS.1 Int (AMS.1 Intensity Alternate Modulation Source)
Specifies the controller ( page 64 of this manual) that will control the "Intensity (Pitch AMS.1 Intensity)."
Intensity (AMS.1 Int AMS Intensity)
Specifies the depth of the pitch modulation effect controlled by "AMS.1 Int ."
[32'...4']
[–12...+12]
[–50...+50]
[–10.0...+10.0]
[OFF...MIDI (CC#83)]
[–99...+99]
[OFF...MIDI (CC#83)]
[–99...+99]
