2–1b: Tone Generator
The Decay and Release that you specify here will control the output level of the oscillator. In order
for these settings to have an effect, they must be set longer than the decay and release of the EG which
you are using for the Amp.
Decay
Specifies the decay time of the tone generato.
Release
Specifies the release time of the tone generator.
2–1c: Overtone
Level
Specifies the volume of the higher overtones that are produced when the tone generator vibrates.
Frequency
Specifies the frequency of the overtones.
Decay
Specifies the decay time of the overtone volume.
2–1d: Pickup Position
Position
Specifies the location of the pickup in relation to the tone generator. With low settings, the pickup will be
placed in the center of the vertical vibration of the tone generator, causing the second partial to be emphasized
and the fundamental to be less audible.
AMS (Alternate Modulation Source)
Selects a modulation source ( page 64 of this manual) that will control "Position."
Intensity (Pickup Position AMS Intensity)
Specifies the depth and direction of the effect of "AMS."
2–1e: Low EQ
Makes settings for a Low EQ (shelving type) that will adjust the output signal.
Frequency (EQ Frequency)
Specifies the cutoff frequency of the Low EQ (shelving type) that will be applied to the output signal.
Gain
Specifies the gain of the Low EQ.
[0...99]
[0...99]
[0...99]
[0...99]
[0...99]
[0...99]
[OFF...MIDI (CC#83)]
[–99...+99]
[0...49]
[–18...+18]
Prog.
Edit
P2
