AMS.2 (Alternate Modulation Source 2)
Selects a modulation source 2 ( page 64 of this manual) which will modify the pitch (e.g., apply vibrato).
Intensity (Pitch AMS.2 Intensity)
Specifies the depth and direction of the pitch change that will be controlled by "AMS.2."
1–3c: Pitch Slope
Specifies how pitch will change in relation to the keyboard (key)
Center Key
Specifies the key at which Lower/Higher keyboard tracking will begin to apply.
Low Slope
Specify the depth and direction of the pitch change that will occur for notes below the "Center Key."
High Slope
Specifies the depth and direction of the pitch change that will occur for notes above the Center Key.
When Low Slope and High Slope are set to +2.0, playing one octave upward from the Center Key will cause the
pitch to rise two octaves.
With a setting of –1.0, playing one octave upward will cause the pitch to fall one octave. With a setting of 0.0, the
notes in the respective areas will produce the same pitch as the Center Key. To play pitches normally, set this
parameter to +1.0.
1–4: OSC 2 Pitch
Here, you can make settings for the oscillator type, basic pitch, pitch keyboard tracking, and pitch
modulation of oscillator 2. The parameters of oscillator 2 are the same as for oscillator 1. (Refer to the
explanation of the "1–3: OSC 1 Pitch" page).
1–5: Sub Pitch
Here, you can make settings for the oscillator type, basic pitch, pitch keyboard tracking, and pitch
modulation of sub oscillator . The parameters of sub oscillator are the same as for oscillator 1. (Refer
to the explanation of the "1–3: OSC 1 Pitch" page).
Pitch
Int=+2.0 Int=+1.0
C9
Int=-1.0
Int=0.0
C-1
Key
C-1 C4 C9
Center Key
[OFF...MIDI (CC#83)]
[–99...+99]
[C–1...G9]
[–1.00...+2.00]
[–1.00...+2.00]
Prog.
Edit
P1
