1-2: Osc Basic - Korg Synthesizer User Manual

1–2: OSC Basic
1–2a
1–2b
1–2c
1–2d
1–2a: Multi Oscillator Synthesis Setup
Here, you can make settings for the oscillator.
The parameters that are set in "2-1: OSC 1" and "2-2: OSC 2" will differ depending on the oscillator
type that is selected here.
OSC 1 (Oscillator 1 Type)
Selects the oscillator type for oscillator 1.
01: Standard
02: Comb Filter
03: VPM (Variable Phase Modulation OSC)
04: Resonance
05: Ring Modulation
06: Cross Modulation
07: Sync Modulation
08: Organ Model
09: Electric Piano Model
10: Brass Model
11: Reed Model
12: Plucked String Model
13: Bowed String Model
When 10: Brass Model, 11: Reed Model, 12: Plucked String Model, or 13: Bowed String Model are selected,
OSC 2 cannot be used.
OSC 2 (Oscillator 2 Type)
Selects the oscillator type for oscillator 2. Refer to OSC 1.
1–2b: Common Pitch Modulation
Creates time-varying changes in the pitch of all oscillators (oscillators 1 and 2, and the sub oscillator).
AMS (Alternate Modulation Source)
Selects the modulation source ( page 64 of this manual) that will control the pitch of all oscillators (oscillators
1 and 2, and the sub oscillator).
Intensity (Common Pitch AMS Intensity)
Specifies the depth and direction of the effect produced by AMS.
[01: Standard...13: Bowed String Model]
[01: Standard...09: Electric Piano Model]
[OFF...MIDI (CC#83)]
[–99...+99]
