Download this manual
VDSL Ethernet
Extender over Coax
AT-MC606

Installation Guide

613-001383 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT-MC606 and is the answer not in the manual?

Questions and answers

Related Manuals for Allied Telesis AT-MC606

Summary of Contents for Allied Telesis AT-MC606

  • Page 1: Installation Guide

    VDSL Ethernet Extender over Coax AT-MC606 Installation Guide 613-001383 Rev. A...
  • Page 2 Copyright © 2010 Allied Telesis, Inc. All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesis, Inc. Allied Telesis and the Allied Telesis logo are trademarks of Allied Telesis, Incorporated. All other product names, company...
  • Page 3 European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment This Allied Telesis RoHS-compliant product conforms to the European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment. Allied Telesis ensures RoHS conformance by requiring supplier Declarations of Conformity, monitoring incoming materials, and maintaining manufacturing process controls.
  • Page 4 Important: The symbol indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements”. This is posted on the Allied Telesis website at http://www.alliedtelesis.com/support/software/. Refer to “Where to Find Web-based Guides” on page 13 to navigate to this document.

  • Page 5: Table Of Contents

    Multiple Dwelling Unit (MDU) Topology.........................26 IP Surveillance Topology...............................27 Chapter 2: Reviewing Safety Precautions ..............................30 Selecting a Site for the AT-MC606 VDSL Network Extender ....................31 Required Cabling ..................................32 Unpacking the AT-MC606 VDSL Network Extender ......................33 Installing the AT-MC606 VDSL Network Extender Subscriber Unit..................34 Using the Subscriber Unit on a Desktop........................34...
  • Page 6 Contents...
  • Page 7 Figure 12. Attaching Protective Feet ...........................38 Figure 13. Configuring AT-MC606 Ethernet Extender for Provider Mode ................39 Figure 14. Rack Mount - Set on Slider..........................40 Figure 15. Rack Mount - Set in Rack...........................40 Figure 16. Connecting AT-MC606 Ethernet Port to an Internet Service Provider ...............41...
  • Page 8 Figures...
  • Page 9 List of Tables Table 1. Safety Symbols ..............................12 Table 2. RJ-45 Port Pinouts ...............................20 Table 3. Front Panel Status LEDs ............................21 Table 4. VDSL Configuration DIP Switches ........................22 Table 5. AT-MC606 Cables ..............................32...
  • Page 10 Tables...

  • Page 11: Preface

    Preface This guide contains instructions on how to install the AT-MC606 VDSL Network Extender and contains the following sections: “Safety Symbols Used in this Document” on page 12 “Where to Find Web-based Guides” on page 13 “Contacting Allied Telesis” on page 14...

  • Page 12: Safety Symbols Used In This Document

    Preface Safety Symbols Used in this Document This document uses the safety symbols defined in Table 1. Table 1. Safety Symbols Symbol Meaning Description Caution Performing or omitting a specific action may result in equipment damage or loss of data. Warning Performing or omitting a specific action may result in electrical shock.

  • Page 13: Where To Find Web-Based Guides

    (PDF) on our web site. Go to http://www.alliedtelesis.com/support/software/. Enter your hardware product model in the Search by Product Name field; for example, enter AT-MC606. You can view the documents online or download them onto your local workstation or server.

  • Page 14: Contacting Allied Telesis

    This section provides Allied Telesis contact information for technical support as well as sales and corporate information. Online Support You can request technical support online by accessing the Allied Telesis Knowledge Base: www.alliedtelesis.com/support/kb.aspx. You can use the Knowledge Base to submit questions to our technical support staff and review answers to previously asked questions.
  • Page 15 Chapter 1 Overview The AT-MC606 VDSL Network Extender product is designed to extend Ethernet traffic using VDSL technology over coaxial cable. This chapter contains the following sections: “Summary of Features” on page 16 “AT-MC606 Port Descriptions” on page 18 “Status LEDs” on page 21 “VDSL Configuration DIP Switches”...

  • Page 16: Chapter 1: Summary Of Features

    12V DC external power supply input port Installation on desktop, wall, DINRAIL, or rack mounting in an AT-MCR12 Media Conversion Rack-Mount Chassis Fully EU RoHS and China RoHS compliant Figure 1. illustrates the front panel of the AT-MC606 VDSL Network Extender. Ethernet VDSL Configuration...

  • Page 17: Figure 2. At-Mc606 Rear Panel

    AT-MC606 VDSL Network Extender Installation Guide Figure 2. illustrates the rear panels of the AT-MC606 VDSL Network Extender. 12VDC 1563A 12 VDC Power Supply Port Figure 2. AT-MC606 Rear Panel...

  • Page 18: At-Mc606 Port Descriptions

    Extender is configured as a Provider unit and the other as a Subscriber unit. 10Base-T/ The AT-MC606 VDSL Network Extender has one 10Base-T/100Base-Tx Ethernet port which allows you to connect one AT-MC606 configured as a 100Base-Tx Subscriber unit to an Ethernet device and a second AT-MC606 configured Ethernet Port as a Provider unit to an Ethernet Local Area Network (LAN) in the building equipment room.
  • Page 19 The AT-MC606 Ethernet port ends up in the half-duplex mode if it is connected to an end-node with a fixed full-duplex mode. This configuration can produce network performance problems.

  • Page 20: Figure 3. Rj-45 10Base-T/100Base-Tx Connector Pin Assignments

    Overview RJ-45 Port Pinouts The pin assignments of an RJ-45 10Base-T/100Base-TX connector and port are illustrated in Figure 3. Figure 3. RJ-45 10Base-T/100Base-TX Connector Pin Assignments Table 2 lists the RJ-45 10Base-T/100Base-TX connector pins and their signals when the port is operating in either MDI or MDI-X configuration. Table 2.

  • Page 21: Status Leds

    AT-MC606 VDSL Network Extender Installation Guide Status LEDs The AT-MC606 VDSL Network Extender features the status LEDs and are defined in Table 3. Table 3. Front Panel Status LEDs Color Description GREEN Power is applied to the unit. Power is not applied to the unit.

  • Page 22: Vdsl Configuration Dip Switches

    Overview VDSL Configuration DIP Switches VDSL Switch The AT-MC606 VDSL Network Extender features the four VDSL Configuration DIP switches on the front panel. The UP/DOWN positions of Definitions each switch are shown in “VDSL Configuration DIP Switches” on page 23 and defined in Table 4 below.

  • Page 23: Vdsl Configuration Dip Switch Descriptions

    The SCBR/PROV (Left) switch defines the function of the AT-MC606 as either a Subscriber or a Provider unit. The Subscriber (SCBR) position is selected when the AT-MC606 is used at the end point of the coaxial VDSL line where the Ethernet lines are distributed to the end-user. The Provider (PROV) position is selected when the AT-MC606 is used as the source for the coaxial VDSL line.
  • Page 24 Overview ASYM/SYM VDSL Configuration Switch The ASYM/SYM (Right Center) switch selects the maximum data rate for the VDSL line. The ASYM (asymmetrical) position is the factory default position, which allows the Subscriber a maximum receive data rate of 100 Mbps and a maximum transmit data rate of 60 Mbps. The SYM (symmetrical) position limits the receive and transmit line rates in a symmetrical manner so the line rates in both directions are approximately the same.

  • Page 25: External Ac/Dc Power Adapter

    An external, energy efficient, AC/DC power adapter is included with the AT-MC606 VDSL Network Extender for desktop or wall-mount operation. The power adapter supplies 12V DC to the AT-MC606. Allied Telesis supplies an approved safety compliant AC power adapter specifically designed for each region where the AT-MC606 VDSL Network Extender is sold.

  • Page 26: Applications For The At-Mc606 Vdsl Network Extender

    Overview Applications for the AT-MC606 VDSL Network Extender The AT-MC606 VDSL Network Extender is designed to be used in pairs to extend Ethernet traffic over existing coaxial cables in a building. One AT-MC606 is configured as the subscriber unit and the second unit is configured as the provider unit.

  • Page 27: Ip Surveillance Topology

    VDSL EXTENDED ETHERNET Figure 6. IP Surveillance Point-to-Point Topology In this case, each AT-MC606 Provider unit is installed within 100 meters of its IP Surveillance camera and is connected with a standard Ethernet cable. (Since the AT-MC606 features auto MDI/MDI-X, you may use either a cross-over or straight-through cable.)The AT-MC606 Subscriber units...

  • Page 28: Chapter 2 Reviewing Safety Precautions

    Chapter 2 Installation This chapter contains the installation procedures for the AT-MC606 VDSL Network Extender in the following sections: “Reviewing Safety Precautions” on page 30 “Selecting a Site for the AT-MC606 VDSL Network Extender” on page 31 “Required Cabling” on page 32 “Unpacking the AT-MC606 VDSL Network Extender”...

  • Page 29: Reviewing Safety Precautions

    Enter your hardware product model in the Search by Product Name field; for example, enter AT-MC606. You can view the documents online or download them onto your local workstation or server. Warning: Do not work on equipment or cables during periods of lightning activity.

  • Page 30: Selecting A Site For The At-Mc606 Vdsl Network Extender

    Observe the following requirements when choosing a site for your AT-MC606 VDSL Network Extender: If you plan to install a AT-MC606 VDSL Network Extender into an AT- MCR12 rackmount chassis and equipment rack, check to be sure that the rack is safely secured and that it will not tip over. Devices in a rack should be installed starting at the bottom, with the heavier devices near the bottom of the rack.

  • Page 31: Required Cabling

    Overview Required Cabling The AT-MC606 VDSL Network Extender requires two or more of the three cables described in Table 5 below. These cables are not shipped with the AT-MC606. Table 5. AT-MC606 Cables Port Cable Connector Ethernet Category 3 or better...

  • Page 32: Unpacking The At-Mc606 Vdsl Network Extender

    1. Remove all components from the shipping package and store the packaging material in a safe location. 2. Make sure the following hardware components are included in your AT-MC606 package. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. One AT-MC606 VDSL Network Extender...

  • Page 33: Installing The At-Mc606 Vdsl Network Extender Subscriber Unit

    Overview Installing the AT-MC606 VDSL Network Extender Subscriber Unit The AT-MC606 Subscriber unit is normally used as a stand-alone device, or can be used as a desktop device, or mounted to a wall. Using the To use the Subscriber unit on a desktop, perform the following procedure: Subscriber Unit 1.

  • Page 34: Wall-Mounting The Subscriber Unit

    Cabling the To cable the Subscriber unit to a computer, perform the following steps: Subscriber Unit 1. Connect the Ethernet cable from the AT-MC606 Ethernet port to the Ethernet port on your computer, as shown in Figure 9. 10 B as...

  • Page 35: Figure 10. Vdsl Line To Wall/Interior Coaxial Cable

    LIN K RA TE 1938 Subscriber Unit Provider Unit Wall/Interior Coax Cable Used as VDSL Line Figure 10. VDSL Line to Wall/Interior Coaxial Cable Note The AT-MC606 coax connector has a built-in termination, so an external termination is not required.

  • Page 36: Powering On The Subscriber Unit

    AT-MC606 VDSL Network Extender Installation Guide Powering On the Power on the Subscriber unit using the power adapter provided, as shown in Figure 11. Subscriber Unit 1 2 V D Figure 11. Power On the AT-MC606 Unit...

  • Page 37: Installing The At-Mc606 Vdsl Network Extender Provider Unit

    Overview Installing the AT-MC606 VDSL Network Extender Provider Unit The AT-MC606 Provider unit can either be installed in an AT-MCR12 rackmount chassis, or used as a desktop device, or mounted onto a wall. Warning To prevent exposure to electric shock, the AT-MC606 Provider Unit must be installed in a RESTRICTED ACCESS LOCATION and performed by QUALIFIED SERVICE PERSONNEL.

  • Page 38: Wall-Mounting The Provider Unit

    “Powering On the Provider Unit” on page 41 for powering the unit. Wall-Mounting The AT-MC606 VDSL Network Extender may be wall mounted directly to the wall with an AT-WLMT Wall Mount Bracket or by using an Allied the Provider Unit Telesis DINRAIL Bracket in conjunction with a previously mounted DINRAIL.

  • Page 39: Rack-Mounting The Provider Unit

    Overview Rack-Mounting To install the Provider unit in an AT-MCR12 rackmount chassis, perform the following steps: the Provider Unit 1. Configure the right VDSL CONFIG switch (SCBR/PROV) to the SCBR position as shown in Figure 13 on page 39. 2. Attach the unit to one of the sliders that holds the unit in the chassis, as shown in Figure 14.

  • Page 40: Cabling The Provider Unit

    For detailed information on how to power on the AT-MCR12 rackmount chassis, refer to the AT-MCR12 Media Converter Rackmount Chassis Installation Manual. If you have installed a stand alone AT-MC606 Provider unit, power on the unit using the power adapter provided, as shown in Figure 11 on page 37.

  • Page 41: Chapter 3: Leds

    Technical Support Department. LEDs Check the LEDs on the AT-MC606 front panel for proper operation. Refer to “AT-MC606 Front Panel” on page 16 for the LED locations and Table 3 on page 21 for the LED functional descriptions. Power LED Check the PWR LED on the front of the AT-MC606 VDSL Network Extender.
  • Page 42 Category 3 or better for 10 Mbps operation, Category 5 and Category 5E for 100 Mbps operation. Make sure that the operating parameters of the port on the AT-MC606 are compatible with the end node to which the port is connected. LINK LED - Coaxial VDSL LINE Port...

  • Page 43: Physical Specifications

    Appendix A Technical Specifications Physical Specifications Dimensions: (W x D x H) 109 mm x 95 mm x 25 mm (4.29 in. x 3.74 in. x 0.98 in.) Weight: .3 kg (0.66 lbs) Recommended Minimum Clearance on All Sides: 5.08 cm (2.0 in.) Environmental Specifications Operating Temperature: 0°...

  • Page 44: Safety And Electromagnetic Compatibility Certifications

    AT-MC606 VDSL Network Extender Installation Guide Safety and Electromagnetic Compatibility Certifications Emission: EN55022 Class B, FCC Part 15 Class B Immunity: EN55024 Safety: EN60950-1, UL60950-1...
