- Page 1 Extended ® Ethernet AT-MC601 AT-MC602 (For use with an AT-MCR12 Only) ◆ Installation User’s Guide PN 613-50538-00 Rev C...
- Page 2 Copyright © 2004 Allied Telesyn, Inc. www.alliedtelesyn.com All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn, Inc. Microsoft is a registered trademark of Microsoft Corporation, Netscape Navigator is a registered trademark of Netscape Communications Corporation.
-
Page 3: Electrical Safety And Emission Statement
Electrical Safety and Emission Statement Standards: This product meets the following standards. U.S. Federal Communications Commission Radiated Energy Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. - Page 4 Electrical Safety and Emission Statement Belangrijk: Appendix C bevat vertaalde veiligheidsopmerkingen voor het installeren van deze apparatuur. Wanneer u de ziet, raadpleeg Appendix C voor vertaalde veiligheidsinstructies in uw taal. Important: L'annexe C contient les instructions de sécurité relatives à l'installation de cet équipement. Lorsque vous voyez le symbole , reportez-vous à...
-
Page 5: Table Of Contents
Additional Compliance Warning Statements ..........................22 Selecting a Site for the Network Extender ..............................23 Cables Not Included ......................................24 Unpacking the Network Extender .................................25 Installing the AT-MC601 Subscriber Unit ..............................26 Using the Subscriber Unit on a Desktop ............................26 Wall-Mounting the Subscriber Unit ..............................26... - Page 6 Contents Cabling the Subscriber Unit ................................... 28 Powering On the Subscriber Unit ................................ 29 Installing the AT-MC602 Provider Unit ................................ 30 Cabling the Provider Unit ..................................31 Powering On the Provider Unit ................................33 Warranty Registration ......................................34 Chapter 3 Configuration ........................................
-
Page 7: Preface
Preface This guide contains instructions on how to install and configure the AT-MC601 and AT-MC602 Extended Ethernet units. How This Guide is Organized This manual contains the following chapters and appendices: Chapter 1, Product Description, describes the features and components of the network extenders. -
Page 8: Document Conventions
Preface Document Conventions This document uses the following conventions: Note Notes provide additional information. Warning Warnings inform you that performing or omitting a specific action may result in bodily injury. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. -
Page 9: Contacting Allied Telesyn Technical Support
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Contacting Allied Telesyn Technical Support This section provides Allied Telesyn contact information for technical support as well as sales or corporate information. Online Support You can request technical support online by accessing the Allied Telesyn Knowledge Base from the following web site: http://kb.alliedtelesyn.com. -
Page 10: Product Description
Chapter 1 Product Description The AT-MC601, AT-MC602 Extended Ethernet products are designed to transmit data at very high speeds over unshielded pairs of copper wires using VDSL technology on your existing telephone line. Summary of Features ❑ VDSL (Very high-bit-rate Digital Subscriber) Line port ❑... -
Page 11: Overview
(MTU), and in the hospitality industry, such as airports, hotels, and convention centers. These units are sold in pairs with the AT-MC601 functioning as the subscriber and the AT-MC602 functioning as the provider. In an MDU, such as a university dormitory, the subscriber unit would be installed in each room and connected to a provider unit through the telephone outlet. -
Page 12: Location Of Components
Product Description Location of Components Figure 2 illustrates the front panels of the AT-MC601 and AT-MC602 network extenders. AT-MC601 10BaseT/ Ethernet LINE VDSL Line 100BaseTX LINK Status LEDs LINK PSTN LEDs MGMT AT-MC601 VDSL EXTENDED ETHERNET VDSL Line Port Management Port... -
Page 13: Hardware Features
The AT-MC602 unit can only be installed in an AT-MCR12 chassis. VDSL Line Port The VDSL Line port allows you to connect the AT-MC601 Subscriber unit to a telephone jack (wall outlet) and the AT-MC602 Provider unit to the inside phone line at the wiring closet. The two units need to be within 1,200 meters of each other in order for the port to operate properly. -
Page 14: Pstn Port
Product Description PSTN Port The PSTN port allows you to connect the AT-MC601 Subscriber unit to a telephone and the AT-MC602 Provider unit to the outside telco box. This port features an RJ-11 connector. Table 2 lists the RJ-11 port pinouts and their assignments. - Page 15 AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Auto-Negotiation.The network extenders Auto-Negotiate the speed and duplex mode of the Ethernet link, so that the link comes up in the highest performance configuration supported by both ends. Half- and Full-duplex Mode.Duplex mode refers to the way an end-node sends and receives data on the network.
-
Page 16: Status Leds
The AT-MC601 and AT-MC602 network extenders feature the following status LEDs: ❑ Power ❑ Ethernet: link and activity ❑ VDSL Line: link and error Table 4 defines the LEDs for the AT-MC601 and AT-MC602 network extenders. Table 4 Status LEDs Table 5 Color... -
Page 17: Management Cable
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Management The management cable included with the AT-MC602 Provider unit features a 9-pin RS-232 connector to attach to your computer and an Cable 8-pin DIN connector to attach to the network extender. -
Page 18: Ac Power Supply Input Port
Product Description AC Power Supply Input Port The network extender has a single DC power supply socket on the back panel. The unit does not have a power switch. To turn the network extender ON or OFF, you connect or disconnect the power cord. External AC/DC An external AC/DC power adapter is included with the network extender for desktop or wall-mount operation. -
Page 19: Software Features
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Software Features The AT-S57 software used to configure the AT-MC601 and AT-MC602 network extenders has the following features: ❑ Determine the VDSL link status ❑ Set the upstream and downstream data transfer rates ❑... -
Page 20: Chapter 2 Installation
The installation process is described in the following sections: ❑ Installation Safety Precautions ❑ Selecting a Site for the Network Extender ❑ Required Cables ❑ Unpacking the Network Extender ❑ Installing the AT-MC601 Subscriber Unit ❑ Installing the AT-MC602 Provider Unit ❑ Warranty Registration... -
Page 21: Installation Safety Precautions
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Installation Safety Precautions Please review the following safety precautions before you begin to install the network extenders. Refer to ”Translated Electrical Safety and Emission Information” on page 54 for translated safety statements in your language. -
Page 22: Additional Compliance Warning Statements
Installation Additional Additional telecommunication-related compliance warning statements used with the AT-MC601 and AT-MC602 Extended Ethernet units are Compliance listed below: Warning Statements Warning When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electronic shock and injury to persons, including the following: 1. -
Page 23: Selecting A Site For The Network Extender
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Selecting a Site for the Network Extender Observe the following requirements when choosing a site for your network extender: ❑ Make sure that the AT-MC602 Provider unit is installed in the AT-MCR12 chassis. -
Page 24: Cables Not Included
Installation Cables Not Included The AT-MC601 and AT-MC602 network extenders require the three cables described in Table 7 below. These cables are not included with the network extenders. Table 7 Cables Port Cable Connector Ethernet Category 3 or better RJ-45... -
Page 25: Unpacking The Network Extender
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Unpacking the Network Extender To unpack the network extender: 1. Remove all components from the shipping package and store the packaging material in a safe location. Note You must use the original shipping material if you need to return the unit to Allied Telesyn. -
Page 26: Installing The At-Mc601 Subscriber Unit
Installation Installing the AT-MC601 Subscriber Unit The AT-MC601 Subscriber unit will most likely be used as a stand-alone device, or can be used as a desktop device, or mounted onto a wall, using the keyholes on the bottom of the unit. The screws and plastic anchors used for mounting the unit are provided. - Page 27 AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) 3. Install the screws and plastic anchors onto the wall, as shown in Figure 7. Figure 7 Installing the Screws and Plastic Anchors Onto The Wall 4. Position the switch onto the wall screws so that the ports are facing the ceiling, as shown in Figure 8.
-
Page 28: Cabling The Subscriber Unit
Installation Cabling the To cable the Subscriber unit, perform the following steps: Subscriber Unit 1. First, connect the Ethernet cable from the Ethernet port to the Ethernet port on the computer, as shown in Figure 9. 10 Ba se 10 0B as eT X LI NK AC T... -
Page 29: Powering On The Subscriber Unit
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) 3. Next, connect a telephone line cable from the VDSL Line port to the wall/interior telephone line, as shown in Figure 11, so that the Subscriber unit can communicate with the Provider unit. -
Page 30: Installing The At-Mc602 Provider Unit
Installation Installing the AT-MC602 Provider Unit The AT-MC602 Provider unit can only be installed in an AT-MCR12 rackmount chassis. Warning To prevent exposure to electric shock, the AT-MC602 Provider Unit must be installed in a RESTRICTED ACCESS LOCATION and performed by QUALIFIED SERVICE PERSONNEL. Note For Finland, Norway, and Sweden –... -
Page 31: Cabling The Provider Unit
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) 2. Then, set the slider in the chassis, as shown in Figure 14. PO W ER Figure 14 Rack Mount - Set in Rack Cabling the To cable the Provider unit, perform the following steps: Provider Unit 1. - Page 32 Installation 2. Then, connect a telephone line cable from the PSTN port to the outside telco box, as shown in Figure 16. Telco Line Figure 16 PSTN to Telco PBX Line 3. Next, connect a telephone line cable from the VDSL Line port to the wall/interior telephone line, as shown in Figure 17, so that the Provider unit can communicate with the Subscriber unit.
-
Page 33: Powering On The Provider Unit
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Powering On Powering on the AT-MC602 Provider Unit requires that the host equipment, AT-MCR12 rackmount chassis, is powered on as well. the Provider Unit Warning The QUALIFIED SERVICE PERSONNEL must verify that the AT-MCR12 power cord is connected to the socket provided with the ground conductor. -
Page 34: Warranty Registration
Installation Warranty Registration When you have finished installing the network extender, register your product by completing the enclosed warranty card and mailing it to Allied Telesyn. -
Page 35: Chapter 3 Configuration
Chapter 3 Configuration The configuration software allows you to adjust and monitor the operating parameters of the media converter. Some of the functions that you can perform with the software include: ❑ Determine the VDSL link status ❑ Set the upstream and downstream data transfer rates ❑... -
Page 36: Starting A Configuration Session
Configuration Starting a Configuration Session Downloading In order to configure and manage your AT-MC601 and AT-MC602 VDSL network extenders, you need to download a copy of the configuration Software software onto the computers you will use to manage the units. The AT-... -
Page 37: Opening The Configuration Software
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Opening the Open the configuration software by double-clicking the “ATS57” application icon, as you would with any other software program. The AT- Configuration MC60x Configurator pop-up will appear, as shown in Figure 19. -
Page 38: Configuring The Provider Unit
Configuration Configuring the Provider Unit After performing the procedure described in the previous section, ”Starting a Configuration Session” on page 36, if you are connected to the Provider unit, the AT-MC60x Configurator menu will appear. The Configurator bar at the top of the menu indicates whether or not the Provider unit has established an Ethernet link by displaying [link DOWN] or [link UP] in brackets. - Page 39 AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) The parameters on the Configuration screen are described below. Upstream/Downstream The upstream and downstream data transfer rate. ❑ Actual (Mbps) Displays the actual data transfer rate on the line. The software automatically detects this speed.
- Page 40 Configuration The Configuration Saved pop-up shown in Figure 22 will appear when the set rate or the highest possible rate has been achieved. Figure 22 Configuration Saved An unsuccessful configuration attempt may include the following status reports: Loading defaults Can’t read link status Done These negative status reports may also be accompanied by error message pop-ups.
-
Page 41: Vdsl Status
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) VDSL Status To view the VDSL Status screen, click on the VDSL Status tab at the top of the menu. The VDSL Status screen is displayed in Figure 23. - Page 42 Configuration Reduced Constellation Link A lesser QAM constellation, causing reduced line rates. If the full constellation rate cannot be achieved because the received SNR is too low, then a reduced constellation link can be established and the software can automatically configure the Subscriber unit parameters. TC Synchronized Transmission convergence is synchronized.
-
Page 43: Ethernet Status
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Ethernet Status To view the Ethernet Status screen, click on the Ethernet Status tab at the top of the menu. The Ethernet Status screen is displayed in Figure 24. - Page 44 Configuration Stop/Start This button allows you to pause counting. When you press Stop, the counters remain at their present values. When you press Start, the counters continue adding to the values already recorded by the software. Local/Remote Select Local to view the parameters for the Provider unit. Select Remote to view the parameters for the Subscriber unit.
-
Page 45: Configuring The Subscriber Unit
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Configuring the Subscriber Unit In rare instances, you may need to use the configuration software on the Subscriber unit to attempt link recovery. If the configuration software detects a problem with the Subscriber unit while you are connected to the Provider unit, it will prompt you to use the software on the Subscriber unit by displaying a pop-up error message. - Page 46 Configuration Install The Install mode enables a watchdog timer to monitor the link attempt process. If the network extenders are not able to establish a link using the parameters you set on the Provider unit within a reasonable amount of time, a timeout will occur. After a timeout, the default configuration parameters will be used to establish a link with the highest possible speed.
-
Page 47: Chapter 4 Troubleshooting
Chapter 4 Troubleshooting This chapter contains information on how to troubleshoot the AT-MC601 and AT-MC602 network extenders in the event a problem occurs. Note If after following the instructions in this chapter you are unable to resolve the problem, contact Allied Telesyn Technical Support for assistance. -
Page 48: Leds
Troubleshooting LEDs Check the PWR LED on the front of the network extender. If the LED is OFF, indicating that the network extender is not receiving power, do the following: ❑ If the network extender is inserted in the AT-MCR12 chassis, make sure that the power cord is securely connected to the power source and to the power connector on the back panel of the AT-MCR12 chassis. -
Page 49: Error Messages
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Error Messages When using the configuration software, you may encounter the following error messages: ❑ “ No answer from device ,” as shown in Figure 27 Figure 27 No Answer Error Message... - Page 50 Troubleshooting ❑ “ P side must be connected to start this procedure” or “S side must be connected to start this procedure ” These error messages occur when the management cable is connected to the wrong unit for the procedure you are trying to perform.This could happen if you switch the management cable between the units without closing the software window.
-
Page 51: Default Configuration Settings
Appendix A Default Configuration Settings This appendix lists the AT-MC601 and AT-MC602 default settings. Table 8 AT-MC601, AT-MC602 Default Settings Setting Default Provider Parameters Monitored Local (Provider) Speeds Upstream Max .94 Mbps Upstream Min .94 Mbps Downstream Max .94 Mbps Downstream Min .94 Mbps... -
Page 52: Technical Specifications
Appendix B Technical Specifications Physical Specifications Dimensions: (W x D x H) 109 mm x 95 mm x 25 mm (4.29 in. x 3.74 in. x 0.98 in.) Weight: .27 kg (0.6 lbs) Recommended Minimum Clearance on All Sides: 5.08 cm (2.0 in.) Environmental Specifications Operating Temperature: 0°... -
Page 53: Safety And Electromagnetic Compatibility Certifications
AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Safety and Electromagnetic Compatibility Certifications Emission: EN55022 Class A Immunity: EN55024 Safety: EN60950... -
Page 54: Translated Electrical Safety And Emission Information
Appendix C Translated Electrical Safety and Emission Information Important: This appendix contains multiple-language translations for the safety statements in this guide. Wichtig: Dieser Anhang enthält Übersetzungen der in diesem Handbuch enthaltenen Sicherheitshinweise in mehreren Sprachen. Vigtigt: Dette tillæg indeholder oversættelser i flere sprog af sikkerhedsadvarslerne i denne håndbog. - Page 55 AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Standards: This product meets the following safety standards. U.S. Federal Communications Commission Radiated Energy Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules.
- Page 56 Translated Electrical Safety and Emission Information Normen: Dieses Produkt erfüllt die Anforderungen der nachfolgenden Normen. Hochfrequenzstörung EN55022 Klasse A, FCC Part 15 Klasse A, C-TICK Störsicherheit EN55024 Elektrische Sicherheit EN60950, UL60950, FCC Part 68 Sicherheit Bitte den Adapter nur mit dem mitgelieferten Extender benutzen. Der Konverter AT-MC602 muß...
- Page 57 AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Standarder: Dette produkt tilfredsstiller de følgende standarder. Radiofrekvens forstyrrelsesemission EN55022 Klasse A, FCC Part 15 Klasse A, C-TICK Immunitet EN55024 Elektrisk sikkerhed EN60950, UL60950, FCC Part 68 Sikkerhed Ved installation af converteren må man kun benytte den med købte PSU.
- Page 58 Translated Electrical Safety and Emission Information Eisen: Dit product voldoet aan de volgende eisen. RFI Emissie EN55022 Klasse A, FCC Part 15 Klasse A, C-TICK Immuniteit EN55024 Electrische Veiligheid EN60950, UL60950, FCC Part 68 Veiligheid Gebruik alleen de power adapter die meegeleverd is met de verlenger. De AT-MC602 moet geinstalleerd worden in de AT-MCR12 die uitgerust is met de juiste AC/DC stroomvoorziening.
- Page 59 AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Normes: ce produit est conforme aux normes de suivantes. Eemission d’interférences EN55022 Classe A, FCC Part 15 Classe A, radioélectriques C-TICK Immunité EN55024 Sécurité électrique EN60950, UL60950, FCC Part 68 Sécurité...
- Page 60 Translated Electrical Safety and Emission Information Standardit: Tämä tuote on seuraavien standardien mukainen. Radioaaltojen häirintä EN55022 Luokka A, FCC Part 15 Luokka A, C-TICK Kestävyys EN55024 Sähköturvallisuus EN60950, UL60950, FCC Part 68 Turvallisuus Käytä vain muuntimen mukana toimitettua virtalaitetta. AT-MC602 tulee asentaa AT-MCR12 kehikkoon, joka on varustettu oikein maadoitetulla AC/DC virtalaitteella.
- Page 61 AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Standard: Questo prodotto è conforme ai seguenti standard. Emissione RFI (interferenza di EN55022 Classe A, FCC Part 15 Classe, radiofrequenza) C-TICK Immunità EN55024 Sicurezza elettrica EN60950, UL60950, FCC Part 68 Norme Di Sicurezza Questo dispositivo deve essere alimentato solo mediante il proprio adattatore.
- Page 62 Translated Electrical Safety and Emission Information Sikkerhetsnormer: Dette produktet tilfredsstiller følgende sikkerhetsnormer. RFI stråling EN55022 Klasse A, FCC Part 15 Klasse A, C-TICK Immunittet EN55024 Elektrisk sikkerhet EN60950, UL60950, FCC Part 68 Sikkerhet Ved installation av converteren må man kun benytte den med tilhørende PSU. AT-MC602 må...
- Page 63 AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Padrões: Este produto atende aos seguintes padrões. Emissão de interferência de EN55022 Classe A, FCC Part 15 Classe A, radiofrequência C-TICK Imunidade EN55024 Segurança eléctrica EN60950, UL60950, FCC Part 68 Segurança...
- Page 64 Translated Electrical Safety and Emission Information Estándares: Este producto cumple con los siguientes estándares. Emisión RFI EN55022 Clase A, FCC Part 15 Clase A, C-TICK Inmunidad EN55024 Seguridad eléctrica EN60950, UL60950, FCC Part 68 Seguridad Use únicamente el adaptador de corriente suministrado junto con el extensor. AT-MC602 debe ser instalado en el AT-MCR12, el cual está...
- Page 65 AT-MC601, AT-MC602 Installation and User’s Guide (For Use with AT-MCR12 Only) Standarder: Denna produkt uppfyller följande standarder. Radiostörning EN55022 Klass A, FCC Part 15 Klass A, C-TICK Immunitet EN55024 Elsäkerhet EN60950, UL60950, FCC Part 68 Säkerhet Använd endast medföljande kraftaggregat till DSL konverteraren.
