Page 1: Installation Guide
VDSL Ethernet Extender AT-MC605 Installation Guide 613-001153 Rev. C... - Page 2 Copyright 2009 Allied Telesis, Inc. All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesis, Inc. Allied Telesis and the Allied Telesis logo are trademarks of Allied Telesis, Incorporated. All other product names, company names, logos or other designations mentioned herein are trademarks or registered trademarks of their respective owners.
- Page 3 Manufacturer Name: Allied Telesis, Inc. Declares that the product: VDSL Ethernet Extender Model Number: AT-MC605 This product complies with FCC Part 15B, Class B Limits: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device must not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 4 Translated Safety Statements Important: The indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” (613-000990) posted on the Allied Telesis website at www.alliedtelesis.com and on this product CD.
-
Page 5: Table Of Contents
Multiple Dwelling Unit (MDU) Topology ..........................28 Chapter 2: Installation ...............................30 Reviewing Safety Precautions ..............................31 Selecting a Site for the AT-MC605 Ethernet Extender ......................32 Required Cabling ..................................33 Unpacking the AT-MC605 Ethernet Extender ........................34 Installing the AT-MC605 VDSL Ethernet Extender Subscriber Unit ..................35 Using the Subscriber Unit on a Desktop........................35... - Page 6 Contents...
- Page 7 Figure 15. Rack Mount - Set on Slider..........................41 Figure 16. Rack Mount - Set in Rack...........................42 Figure 17. Connecting AT-MC605 Ethernet Port to an Internet Service Provider ...............42 Figure 18. Connecting AT-MC605 Phone Port to PBX Connection..................43 Figure 19. VDSL Line to Wall/Interior Phone Line.......................43...
- Page 8 Figures...
- Page 9 Table 2. RJ-11 VDSL Line Port Pinouts ..........................18 Table 3. RJ-11 Phone Port Pinouts ............................18 Table 4. RJ-45 Port Pinouts ...............................21 Table 5. Front Panel Status LEDs ............................22 Table 6. VDSL Configuration DIP Switches ........................24 Table 7. AT-MC605 Cables ..............................33...
- Page 10 Tables...
-
Page 11: Preface
Preface This guide contains instructions on how to install the AT-MC605 VDSL Ethernet Extender and contains the following sections: “Safety Symbols Used in this Document” on page 12 “Where to Find Web-based Guides” on page 13 “Contacting Allied Telesis” on page 14... -
Page 12: Safety Symbols Used In This Document
Preface Safety Symbols Used in this Document This document uses the safety symbols defined in Table 1. Table 1. Safety Symbols Symbol Meaning Description Caution Performing or omitting a specific action may result in equipment damage or loss of data. Warning Performing or omitting a specific action may result in electrical shock. -
Page 13: Where To Find Web-Based Guides
AT-MC605 VDSL Ethernet Extender Installation Guide Where to Find Web-based Guides The installation and user guides for all Allied Telesis products are available in portable document format (PDF) on our web site at www.alliedtelesis.com. You can view the documents online or download... -
Page 14: Contacting Allied Telesis
You can contact Allied Telesis for sales or corporate information through our web site at http://www.alliedtelesis.com/purchase. Corporate Information Warranty For warranty information on the AT-MC605 VDSL Ethernet Extender, go to www.alliedtelesis.com/warranty for the specific terms and conditions of the warranty and for warranty registration. -
Page 15: Chapter 1: Overview
Chapter 1 Overview The AT-MC605 VDSL Ethernet Extended product is designed to transmit and receive data at very high speeds over unshielded pairs of copper wires using VDSL technology on your existing private telephone line. This chapter contains the following sections: “Summary of Features”... -
Page 16: Summary Of Features
12V DC external power supply input port Installation on desktop, wall, DINRAIL, or rack mounting in an AT- MCR12 rackmount chassis Fully EU RoHS and China RoHS compliant Figure 1. illustrates the front panel of the AT-MC605 VDSL Ethernet Extender. Ethernet VDSL Configuration... -
Page 17: Figure 2. At-Mc605 Rear Panel
AT-MC605 VDSL Ethernet Extender Installation Guide Figure 2. illustrates the rear panels of the AT-MC605 VDSL Ethernet Extender. 12VDC 1563 12 VDC Power Supply Port Figure 2. AT-MC605 Rear Panel... -
Page 18: At-Mc605 Port Descriptions
One AT-MC605 Ethernet Extender is configured as a Provider unit and the other as a Subscriber unit. The two units need to be within 3,000 meters (9842 feet) of each other in order for the port to operate properly. -
Page 19: 10Base-T/100Base-Tx Ethernet Port
For example, if an end node is capable of only 10 Mbps, the AT-MC605 Ethernet Extender sets its ethernet port to 10 Mbps or if an end node is capable of 100 Mbps, the... - Page 20 Note For Auto-Negotiation to operate properly, the end-nodes connected to the AT-MC605 VDSL Ethernet Extender should also use Auto- Negotiation. If an end-node does not have this feature and has a fixed duplex mode of full-duplex, the result will be a duplex mode mismatch with the end-node.
-
Page 21: Figure 3. Rj-45 10Base-T/100Base-Tx Connector Pin Assignments
AT-MC605 VDSL Ethernet Extender Installation Guide RJ-45 Port Pinouts The pin assignments of an RJ-45 10Base-T/100Base-TX connector and port are illustrated in Figure 3. Figure 3. RJ-45 10Base-T/100Base-TX Connector Pin Assignments Table 4 lists the RJ-45 10Base-T/100Base-TX connector pins and their signals when the port is operating in either MDI or MDI-X configuration. -
Page 22: Status Leds
Overview Status LEDs The AT-MC605 VDSL Ethernet Extender features the status LEDs and are defined in Table 5. Table 5. Front Panel Status LEDs Color Description GREEN Power is applied to the unit. Power is not applied to the unit. - Page 23 AT-MC605 VDSL Ethernet Extender Installation Guide Table 5. Front Panel Status LEDs Color Description After a VDSL link is established, the Rate LED will continuously blink a set number RATE Blinking of times in a set time interval. Each “blink”...
-
Page 24: Vdsl Configuration Dip Switches
Overview VDSL Configuration DIP Switches VDSL Switch The AT-MC605 VDSL Ethernet Extender features the four VDSL Configuration DIP switches on the front panel. The UP/DOWN positions of Definitions each switch are shown in “VDSL Configuration DIP Switches” on page 25 and defined in Table 6 below. -
Page 25: Vdsl Configuration Dip Switch Descriptions
Extender is used at the end point of the VDSL line where the ethernet and phone lines are distributed to the end-user. The Provider (PROV) position is selected when the AT-MC605 Ethernet Extender is used as the source for the VDSL line. Normally, two AT-MC605 Ethernet Extenders work together in tandem - one as a Subscriber unit and the other as a Provider unit. - Page 26 Overview NO LIMIT/RATE LIMIT VDSL Configuration Switch The NO LIMIT/RATE LIMIT (Right Center) switch selects the maximum data rate for the VDSL line. The NO LIMIT position is the factory default for this switch, which allows a maximum downstream data rate of 100 Mbps and and a maximum upstream data rate of 60 Mbps.
-
Page 27: External Ac/Dc Power Adapter
An external, energy efficient, AC/DC power adapter is included with the AT-MC605 VDSL Ethernet Extender for desktop or wall-mount operation. The power adapter supplies 12V DC to the AT-MC605 Ethernet Extender. Allied Telesis supplies an approved safety compliant AC power adapter specifically designed for each region where the AT-MC605 VDSL Ethernet Extender is sold. -
Page 28: Multiple Dwelling Unit (Mdu) Topology
When configured as a subscriber unit, the AT-MC605 Ethernet Extender can be used as a desktop or wallmount device. If the AT-MC605 Ethernet Extender is configured as a provider unit in a wiring closet or telecommunications room, it may be mounted on the wall, on a DINRAIL, or in an AT-MCR12 rackmount chassis in an equipment rack. - Page 29 AT-MC605 VDSL Ethernet Extender Installation Guide individually assigned to each dorm room. The Provider units are rack mounted together in AT-MCR12 chassis where they are connected to the building’s telephone switch and internet service.
-
Page 30: Chapter 2: Installation
This chapter contains the installation procedures for the AT-MC605 VDSL Ethernet Extender in the following sections: “Reviewing Safety Precautions” on page 31 “Selecting a Site for the AT-MC605 Ethernet Extender” on page 32 “Required Cabling” on page 33 “Unpacking the AT-MC605 Ethernet Extender” on page 34 “Installing the AT-MC605 VDSL Ethernet Extender Subscriber Unit”... -
Page 31: Reviewing Safety Precautions
Please review the following safety precautions before you begin to install the AT-MC605 VDSL Ethernet Extender. Only use the power adapter supplied when the AT-MC605 VDSL Ethernet Extender is installed as a stand alone unit. No power adapter is required if the unit is inserted in the AT-MCR12 rackmount chassis. -
Page 32: Selecting A Site For The At-Mc605 Ethernet Extender
Observe the following requirements when choosing a site for your AT-MC605 VDSL Ethernet Extender: If you plan to install a AT-MC605 Ethernet Extender into an AT- MCR12 rackmount chassis and equipment rack, check to be sure that the rack is safely secured and that it will not tip over. Devices in a rack should be installed starting at the bottom, with the heavier devices near the bottom of the rack. -
Page 33: Required Cabling
AT-MC605 VDSL Ethernet Extender Installation Guide Required Cabling The AT-MC605 VDSL Ethernet Extender requires two or more of the three cables described in Table 7 below. These cables are not shipped with the AT-MC605 Ethernet Extender. Table 7. AT-MC605 Cables... -
Page 34: Unpacking The At-Mc605 Ethernet Extender
Overview Unpacking the AT-MC605 Ethernet Extender To unpack the AT-MC605 product: 1. Remove all components from the shipping package and store the packaging material in a safe location. Note You must use the original shipping material if you need to return the unit to Allied Telesis. -
Page 35: Installing The At-Mc605 Vdsl Ethernet Extender Subscriber Unit
AT-MC605 VDSL Ethernet Extender Installation Guide Installing the AT-MC605 VDSL Ethernet Extender Subscriber Unit The AT-MC605 Subscriber unit is normally used as a stand-alone device, or can be used as a desktop device, or mounted to a wall. Using the... -
Page 36: Wall-Mounting The Subscriber Unit
1. To connect a computer to the AT-MC605 Ethernet Extender, connect the ethernet cable from the AT-MC605 ethernet port to the ethernet port on your computer, as shown in Figure 8 , ”Connecting AT-MC605 Ethernet Port to Computer”. 10 B as... -
Page 37: Figure 9. Connecting At-Mc605 Phone Port To Telephone
AT-MC605 VDSL Ethernet Extender Installation Guide 2. To connect a telephone to the AT-MC605 Ethernet Extender, connect a telephone line cable from the Phone port to the telephone, as shown in Figure 9. 10 Ba se -T / 10 0B... -
Page 38: Powering On The Subscriber Unit
Overview Powering On the Power on the Subscriber unit using the power adapter provided, as shown in Figure 11. Subscriber Unit 1 2 V D Figure 11. Power On The Subscriber Unit... -
Page 39: Installing The At-Mc605 Ethernet Extender Provider Unit
AT-MC605 VDSL Ethernet Extender Installation Guide Installing the AT-MC605 Ethernet Extender Provider Unit The AT-MC605 Provider unit can either be installed in an AT-MCR12 rackmount chassis, or used as a desktop device, or mounted onto a wall. Warning To prevent exposure to electric shock, the AT-MC605 Provider Unit must be installed in a RESTRICTED ACCESS LOCATION and performed by QUALIFIED SERVICE PERSONNEL. -
Page 40: Wall-Mounting The Provider Unit
“Powering On the Provider Unit” on page 44 for powering the unit. Wall-Mounting The AT-MC605 VDSL Ethernet Extender may be wall mounted directly to the wall with an AT-WLMT Wall Mount Bracket or by using an Allied the Provider Unit Telesis DINRAIL Bracket in conjunction with a previously mounted DINRAIL. -
Page 41: Rack-Mounting The Provider Unit
To install the Provider unit in an AT-MCR12 rackmount chassis, perform the following steps: the Provider Unit 1. Configure the right VDSL CONFIG switch (SCBR/PROV) to the SCBR position as shown in Figure 14 , ”Configuring AT-MC605 Ethernet Extender for Provider Mode”. VDSL CONFIG SCBR... -
Page 42: Cabling The Provider Unit
1. Connect the ethernet cable from the ethernet port to the Service Provider box (ISP) in your wiring closet, as shown in Figure 17. Internet M C R 1 2 1591 Figure 17. Connecting AT-MC605 Ethernet Port to an Internet Service Provider... -
Page 43: Figure 18. Connecting At-Mc605 Phone Port To Pbx Connection
M C R 1 2 1562 Figure 18. Connecting AT-MC605 Phone Port to PBX Connection 3. Connect a telephone line cable from the VDSL Line port to the wall/ interior telephone line, as shown in Figure 19, so that the Provider unit can communicate with the Subscriber unit. -
Page 44: Powering On The Provider Unit
For detailed information on how to power on the AT-MCR12 rackmount chassis, refer to the AT-MCR12 Media Converter Rackmount Chassis Installation Manual. If you have installed a stand alone AT-MC605 Provider unit, power on the unit using the power adapter provided, as shown in Figure 20. 1 2 V D... -
Page 45: Chapter 3: Troubleshooting
Technical Support Department. LEDs Check the PWR LED on the front of the AT-MC605 Ethernet Extender. If the LED is OFF, indicating that the AT-MC605 Ethernet Extender is not receiving power, do the following:... - Page 46 Check that the twisted pair cable is securely connected to the port on the AT-MC605 Ethernet Extender and to the port on the end node. Make sure that the twisted pair cable does not exceed 100 meters (328 feet).
-
Page 47: Appendix A: Technical Specifications
Appendix A Technical Specifications Physical Specifications Dimensions: (W x D x H) 109 mm x 95 mm x 25 mm (4.29 in. x 3.74 in. x 0.98 in.) Weight: .3 kg (0.66 lbs) Recommended Minimum Clearance on All Sides: 5.08 cm (2.0 in.) Environmental Specifications Operating Temperature: 0°... -
Page 48: Safety And Electromagnetic Compatibility Certifications
Appendix A: Technical Specifications Safety and Electromagnetic Compatibility Certifications Emission: EN55022 Class B, FCC Part 15 Class B Immunity: EN55024 Safety: EN60950, UL60950...
