Page 1: Installation Guide
AT-EX1001SC/GM1 Gigabit Ethernet Multimode Extender Installation Guide PN 613-10857-00 Rev A... - Page 2 Copyright 2000 Allied Telesyn International, Corp. 960 Stewart Drive Suite B, Sunnyvale CA 94085 USA All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn International, Corp. Ethernet is a registered trademark of Xerox Corporation. All other product names, company names, logos or other designations mentioned herein are trademarks or registered trademarks of their respective owners.
-
Page 3: Electrical Safety And Emission Statement
Electrical Safety and Emission Statement Standards: This product meets the following standards. U.S. Federal Communications Commission RADIATED ENERGY Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 5: Table Of Contents
Fiber Optic Port 1 (P1) ................4 Fiber Optic Port 2 (P2) ................4 AC Power Socket ..................4 Port and System LEDs ................5 Installing the AT-EX1001SC/GM1 Multimode Extender........ 6 Planning the Installation ................6 Selecting a Site ................... 7 Verifying Package Contents ..............7 Reviewing Safety Guidelines .............. -
Page 7: Welcome To Allied Telesyn
Welcome to Allied Telesyn This guide contains instructions on how to install the AT-EX1001SC/GM1 Gigabit Ethernet Multimode Extender. Where to Find Web-based Guides The Allied Telesyn web site at www.alliedtelesyn.com provides you with an easy way to access the most recent documentation and technical information for all of our products. -
Page 8: Contacting Allied Telesyn
Contacting Allied Telesyn There are several ways that you can contact Allied Telesyn technical support: online, telephone, fax, or e-mail. Online Support You can request technical support online by filling out the Online Technical Support Form at www.alliedtelesyn.com/forms/support.htm. Telephone and Fax Support Americas Germany United States, Canada, Mexico,... -
Page 9: Returning Products
AT-EX1001SC/GM1 Installation Guide Returning Products Products for return or repair must first be assigned a Return Materials Authorization (RMA) number. A product sent to Allied Telesyn without a RMA number will be returned to the sender at the sender’s expense. -
Page 10: For Sales Or Corporate Information
Tell Us What You Think If you have any comments or suggestions on how we might improve this or other Allied Telesyn documents, please fill out the “AT-EX1001SC/GM1 Installation Guide Feedback” on page 27 and return the form to us at the address or fax number provided. -
Page 11: Overview
Overview The AT-EX1001SC/GM1 Gigabit Ethernet Multimode Extender (Figure 1) allows you to extend the maximum distance of standard multimode fiber cable for 1000Base-SX Gigabit Ethernet beyond the distance limitations imposed by the current IEEE 802.3z standard. With this unit, you can extend your network up to 2 kilometers (1.24 miles) over 50/125 or 62.5/125 micron multimode fiber... -
Page 12: Gigabit Ethernet Technology And Fddi Technology
Figure 2 illustrates a network that incorporates two AT-EX1001SC/GM1 Gigabit Multimode Extenders. The units interconnect an AT-8224XL Fast Ethernet Switch with an AT-A15/SX Expansion Module and an AT-9006... -
Page 13: Features And Components
AT-A15 Expansion Module Figure 2 Example Topology Features and Components The AT-EX1001SC/GM1 Gigabit Ethernet Multimode Extender has the following features: One 1000Base-X fiber optic port (Port 1) with a maximum operating distance of 2 kilometers (1.24 miles) using 50/125 or 62.5/125 micron... -
Page 14: Fiber Optic Port 1 (P1)
2 kilometers (1.24 miles). This port operates in full-duplex mode at 1000 Mbps. Note Port 1 must be connected to Port 1 on another AT-EX1001SC/GM1 Multimode Extender. Do not connect Port 1 to any other type of network device. -
Page 15: Port And System Leds
AT-EX1001SC/GM1 Installation Guide Port and System LEDs The front panel has several LEDs that display the status of the ports and the unit. Table 1 describes the functions of the LEDs. Table 1 AT-EX1001SC/GM1 LED Indicators Description State Indicates System LEDs... -
Page 16: Installing The At-Ex1001Sc/Gm1 Multimode Extender
275 m (754 ft) multimode fiber 220 m (604 ft) 1. Assumes that the opposite end of the fiber cable is connected to P1 on another AT-EX1001SC/GM1 Gigabit Ethernet Mulitmode Extender. Note Do not use single-mode fiber on either port of the AT-EX1001SC/GM1... -
Page 17: Selecting A Site
Make sure that the following items are included in your package, If any of the following items are missing or damaged, contact your Allied Telesyn sales representative. One AT-EX1001SC/GM1 Gigabit Ethernet Multimode Extender Power cord (Americas, EC, Australia, and UK only) This installation guide... - Page 18 Warning Lightning Danger: Do not work on this equipment or cables during periods of lightening activity. ! 9 Warning Power cord is used as a disconnection device: To de-energize equipment, disconnect the power cord. ! 10 Warning Electrical-Type Class 1 Equipment: This equipment must be earthed.
-
Page 19: Installing The Unit
Dust contamination can adversely impact the operation of the ports. Remove the dust cover from Port 1 (P1) on the AT-EX1001SC/GM1 Multimode Extender. Connect the appropriate fiber optic cable to Port 1 (P1) on the Gigabit Ethernet multimode extender. -
Page 20: Troubleshooting
If after connecting one of the units to the host device the PLL Lock and SC LEDs of Port 2 fail to light up, do the following: Make sure that both the host device and the AT-EX1001SC/GM1 Multimode Extender are powered up and functioning properly. -
Page 21: Technical Specifications
Power Consumption 12 watts Warranty Registration The AT-EX1001SC/GM1 Gigabit Ethernet Multimode Extender comes with a Limited Lifetime Warranty. The power supply has a five (5) year warranty. When you have finished installing the unit, you should register your product by completing the enclosed warranty card and sending it in, or by visiting our web site at www.alliedtelesyn.com/forms/warranty.htm and completing... -
Page 23: Translated Safety And Emission Information
Appendix A Translated Safety and Emission Information Important: This appendix contains multiple-language translations for the safety statements in this guide. Wichtig: Dieser Anhang enthält Übersetzungen der in diesem Handbuch enthaltenen Sicherheitshinweise in mehreren Sprachen. Vigtigt: Dette tillæg indeholder oversættelser i flere sprog af sikkerhedsadvarslerne i denne håndbog. - Page 24 Standards: This product meets the following standards. U.S. Federal Communications Commission RADIATED ENERGY Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 25 AT-EX1001SC/GM1 Installation Guide ! 12 PLUGGABLE EQUIPMENT, the socket outlet shall be installed near the equipment and shall be easily accessible. ! 13 CAUTION: Air vents must not be blocked and must have free access to the room ambient air for cooling.
- Page 26 Standarder: Dette produkt tilfredsstiller de følgende standarder. Radiofrekvens forstyrrelsesemission EN55022 Klasse A ADVARSEL: I et hjemligt miljø kunne dette produkt forårsage radio forstyrrelse. Bliver det tilfældet, påkræves brugeren muligvis at tage tilstrækkelige foranstaltninger. Immunitet EN50082-1 Elektrisk sikkerhed EN60950, UL 1950 Laser EN60825 SIKKERHED...
- Page 27 AT-EX1001SC/GM1 Installation Guide Eisen: Dit product voldoet aan de volgende eisen. RFI Emissie EN55022 Klasse A WAARSCHUWING: Binnenshuis kan dit product radiostoring veroorzaken, in welk geval de gebruiker verplicht kan worden om gepaste maatregelen te nemen. Immuniteit EN50082-1 Electrische Veiligheid...
- Page 28 Normes: ce produit est conforme aux normes de suivantes: Emission d’interférences radioélectriques EN55022 Classe A MISE EN GARDE : dans un environnement domestique, ce produit peut provoquer des interférences radioélectriques. Auquel cas, l’utilisateur devra prendre les mesures adéquates. Immunité EN50082 - 1 Sécurité...
- Page 29 AT-EX1001SC/GM1 Installation Guide Standardit: Tämä tuote on seuraavien standardien mukainen. Radioaaltojen häirintä EN55022 Luokka A VAROITUS: Kotiolosuhteissa tämä laite voi aiheuttaa radioaaltojen häiröitä, missä tapauksessa laitteen käyttäjän on mahdollisesti ryhdyttävä tarpeellisiin toimenpiteisiin. Kestävyys EN50082-1 Sähköturvallisuus EN60950, UL 1950 Laser EN60825 TURVALLISUUS VAROITUS Luokan 1 Lasertuote.
- Page 30 Standard: Questo prodotto è conforme ai seguenti standard. Emissione RFI (interferenza di radiofrequenza) EN55022 Classe A AVVERTENZA: in ambiente domestico questo prodotto potrebbe causare radio interferenza. In questo caso potrebbe richiedersi all’utente di prendere gli adeguati provvedimenti. Immunità EN50082-1 Sicurezza elettrica EN60950, UL 1950 Laser EN60825...
- Page 31 AT-EX1001SC/GM1 Installation Guide Sikkerhetsnormer: Dette produktet tilfredsstiller følgende sikkerhetsnormer. RFI stråling EN55022 Klasse A ADVARSEL: Hvis dette produktet benyttes til privat bruk, kan produktet forårsake radioforstyrrelse. Hvis dette skjer, må brukeren ta de nødvendige forholdsregler. Immunitet EN50082-1 Elektrisk sikkerhet EN60950, UL 1950...
- Page 32 Padrões: Este produto atende aos seguintes padrões. Emissão de interferência de radiofrequência EN55022 Classe A AVISO: Num ambiente doméstico este produto pode causar interferência na radiorrecepção e, neste caso, pode ser necessário que o utente tome as medidas adequadas. Imunidade EN50082-1 Segurança Eléctrica EN60950, UL 1950...
- Page 33 AT-EX1001SC/GM1 Installation Guide Estándares: Este producto cumple con los siguientes estándares. Emisión RFI EN55022 Clase A ADVERTENCIA: en un entorno doméstico, este producto puede causar radiointerferencias, en cuyo caso, puede requerirse del usuario que tome las medidas que sean convenientes al respecto.
- Page 34 Standarder: Denna produkt uppfyller följande standarder. Radiostörning EN55022 Klass A VARNING: Denna produkt kan ge upphov till radiostörningar i hemmet, vilket kan tvinga användaren till att vidtaga erforderliga åtgärder. Immunitet EN50082-1 Elsäkerhet EN60950, UL 1950 Laser EN60825 SÄKERHET VARNING! Laserprodukt av klass 1. VARNING! Laserstrålning när enheten är öppen.
-
Page 35: Technical Support Fax Order
Appendix B Technical Support Fax Order Name _________________________________________________________________ Company ______________________________________________________________ Address _______________________________________________________________ City______________________ State/Province_______________________________ Zip/Postal Code ________________ Country_______________________________ Phone ______________________________ Fax _______________________________ Incident Summary Model number of Allied Telesyn product I am using _______________________ Firmware release number of Allied Telesyn product _______________________ Other network software products I am using (e.g., network managers) ______________________________________________________________________ ______________________________________________________________________... -
Page 37: At-Ex1001Sc/Gm1 Installation Guide Feedback
Appendix C AT-EX1001SC/GM1 Installation Guide Feedback Please tell us what additional information you would like to see discussed in this guide. If there are topics you would like information on that were not covered in this guide, please photocopy this page, answer the questions and fax or mail this form back to Allied Telesyn.
