Slide out the top access cover to remove.

Note: If you are removing the top access cover assembly to access another FRU, then leave the operator

panel bezel attached, and you are done. If you are replacing the top access cover assembly FRU, then

remove the separate operator panel bezel FRU. See

"Operator panel bezel removal" on page 4-41

Installation note: When reinstalling the top access cover assembly, guide the speaker and bin full sensor

cables through the two holes (J) on the rear of the top cover first.

Repair information
