Waldorf RN8110G Installation And Operation Manual

Gas target top range static oven
Hide thumbs Also See for RN8110G:
Table of Contents

Advertisement

Quick Links

Download this manual
I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l
Gas Target Top Range
Static Oven
RN8110G
RNB8110G
Date Purchased
Serial Number
Dealer
Service Provider
RNL8110G
RNLB8110G
1
For use in GB & IE
228682-14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RN8110G and is the answer not in the manual?

Questions and answers

Related Manuals for Waldorf RN8110G

Summary of Contents for Waldorf RN8110G

  • Page 1 I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l Gas Target Top Range Static Oven RN8110G RNL8110G RNB8110G RNLB8110G...
  • Page 2 MANUFACTURED BY Moffat Limited Rolleston 7675 New Zealand INTERNATIONAL CONTACTS AUSTRALIA Moffat Pty Limited Web: www.moffat.com.au E.Mail: vsales@moffat.com.au Main Office: (tel) +61 (03) 9518 3888 (fax) +61 (03) 9518 3833 Service: (tel): 1800 622 216 Spares: (tel): 1800 337 963 Customer Service: (tel): 1800 335 315...

  • Page 3: Table Of Contents

    Contents Waldorf Gas Target Top Range Static Oven RN(L)(B)8110G Gas Target Top Range Static Oven . Introduction ....................2 Specifications .................... 3 Model Numbers Covered in this Specification General Gas Supply Requirements Gas Connection Dimensions ....................6 Installation ....................7...

  • Page 4: Introduction

    Introduction We are confident that you will be delighted with your WALDORF Gas Target Top Range Static Oven, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Waldorf appliance, there are two important things you can do.

  • Page 5: Specifications

    Specifications Model Numbers Covered in this Specification RN[1]8110G Gas Target Top Range Static Oven. NOTE: [1]: - Model Options; - Standard. - Low Back. - Bold Front. - Low Back and Bold Front. General A commercial heavy duty, general purpose fully modular, gas fired Target Top Range Static Oven, having a high output, two stage double-ring cast iron burner offering accurate temperature control and infinitely variable heat with heat radiating out from centre of Target Top.

  • Page 6: Gas Supply Requirements

    Specifications Gas Supply Requirements - Australia: Natural Gas LP Gas (Propane) Target Top Oven Target Top Oven Input Rate (N.H.G.C.) 45 MJ/hr 30 MJ/hr 45 MJ/hr 30 MJ/hr Gas Supply Pressure 1.13 - 3.40 kPa 2.75 - 4.50 kPa Burner Operating Pressure (*) 1.0 kPa 2.60 kPa Gas Connection...

  • Page 7: Gas Connection

    Specifications - All Other Markets: Natural Gas Town Gas (**) Target Top Oven Target Top Oven Input Rate (N.H.G.C.) 45 MJ/hr 30 MJ/hr 45 MJ/hr 30 MJ/hr Gas Supply Pressure 1.13 - 3.40 kPa 0.75 - 1.50 kPa Burner Operating Pressure (*) 0.95 kPa 0.63 kPa Gas Connection...

  • Page 8: Dimensions

    Dimensions RN(L)8110G...

  • Page 9: Installation

    Waldorf Gas Target Top Range Static Oven are designed to provide years of satisfactory service and correct installation is essential to achieve the best performance, efficiency and trouble-free operation.

  • Page 10: Clearances

    Gas Connection NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY AN AUTHORISED PERSON. Waldorf Target Top Ranges Static Ovens do not require an electrical connection, as they function totally on gas supply only. It is essential that gas supply is correct for appliance to be installed and that adequate supply pressure and volume are available.
  • Page 11 Installation NOTE: Gas pressure regulator provided with this appliance is convertible between Natural Gas and LPG as shown in ‘Gas Conversion Section’ in this manual. Ensure regulator is converted to correct gas type that appliance will operate on. Regulator outlet pressure is fixed ex-factory for gas type that regulator is converted to and it is NOT to be adjusted.

  • Page 12: Operation

    / operator. Waldorf appliances have been designed to provide simplicity of operation and 100% safety protection. Improper operation is almost impossible, however bad operation practices can reduce the life of the appliance and produce a poor quality product.

  • Page 13: Lighting Pilot Burner - (Target Top)

    Operation Lighting Pilot Burner - (Target Top) Remove centre casting with casting removal tool. Depress control knob and rotate anti-clockwise to ‘PILOT’ position. With control knob depressed, manually light pilot burner located in front of main burner. Hold in control knob for approximately 10 to 15 seconds, then release. Pilot burner should remain alight.

  • Page 14: Lighting Oven Pilot Burner

    Operation Oven Caution Be aware that when opening the oven door, hot air and cooking vapours will be released from the hot oven. Lighting Oven Pilot Burner Pilot Burner ! IMPORTANT viewing holes DO NOT USE aluminium foil or trays directly on cast iron sole plate(s).

  • Page 15: Turning Oven To 'Stand-By' (Pilot 'On' Only)

    Operation Control Knob in Turning Oven to ‘Stand-by’ (Pilot ‘ON’ Only) Pilot Position NOTE: DO NOT attempt to rotate Thermostat Control Knob anti-clockwise back to ‘Pilot’ position as Knob and Gas Valve will be damaged. Rotate thermostat control knob clockwise to ‘Pilot’ Piezo Igniter position.

  • Page 16: Cleaning And Maintenance

    Cleaning and Maintenance General Caution Always turn off gas supply before cleaning. This appliance is not water proof. Do not use water jet spray to clean interior or exterior of this appliance. Clean the Target Top Range Static Oven regularly. A clean appliance looks better, will last longer and will perform better.

  • Page 17: Periodic Maintenance

    Cleaning and Maintenance Target Top a. This should be kept clean of any build up of food spillage. Provided cast iron work surface is regularly used it will maintain itself in good condition with no special cleaning required. b. Clean food residue and spillage from channels around centre casting and main plates before use. c.

  • Page 18: Fault Finding

    Fault Finding This section provides an easy reference guide to the more common problems that may occur during operation of your appliance. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your appliance. Although this section covers the most common problems reported, you may encounter a problem not covered in this section.

  • Page 19: Gas Conversion And Specifications

    Gas Conversion and Specifications Conversion Procedure Caution Ensure Appliance is isolated from gas and electrical supplies before commencing servicing. NOTE:  These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning appliance. ...
  • Page 20 Gas Conversion and Specifications Pilot Burner Disconnect gas supply tube from base of pilot burner. Pilot Burner Main Burner Injectors Remove pilot burner and thermo couple retaining plate. Remove pilot burner from mounting bracket. Remove injector and spring from pilot burner and replace with correct size injector as shown in ‘Gas Specifications Tables’...

  • Page 21: Gas Specifications

    Gas Conversion and Specifications Static Oven Main Burner Carry out the following:-  Remove lower lintel at front of oven. Thermocouple Pilot Burner  Open oven door and remove sole plate(s).  Remove main burner.  Disconnect pilot supply tube from pilot burner to access pilot injector.

  • Page 22: Gas Regulator

    Gas Conversion and Specifications Gas Regulator - NAT Gas / LPG / Butane Only. NOTE, Pin rotated for Natural Gas NOTE: Gas regulator supplied convertible between Natural Gas and LP Gas, but it’s outlet NOTE, Pin rotated pressure is fixed ex-factory for LPG and is NOT to be adjusted.

  • Page 23: Gas Specifications

    Gas Conversion and Specifications Gas Specifications - Australia Nat. Gas LP Gas (Propane) Ø 1.70mm Ø 1.10mm Main Burner Injector (Inner Ring) Ø 2.60mm Ø 1.55mm Main Burner Injector (Outer Ring) 0.35 0.25 Pilot Burner Injector Target Top 25mm 25mm Burner Aeration Screw X (Inner) 28mm 28mm...
  • Page 24 Gas Conversion and Specifications - UK Only: Category: 2H3P. Flue Type: Natural Gas (G20) Propane (G31) Ø 1.70 mm Ø 1.10 mm Main Burner Injector (Inner Ring) Ø 2.60 mm Ø 1.55 mm Main Burner Injector (Outer Ring) 0.35 0.25 Pilot Burner Injector Target Top 25 mm...
  • Page 25 Gas Conversion and Specifications - All Other Markets: Natural Gas Town Gas (**) Main Burner Injector (Inner Ring) Ø 1.70mm Ø 4.20mm Main Burner Injector (Outer Ring) Ø 2.60mm Ø 6.30mm Pilot Injector 0.35 0.70 Target Top Burner Aeration Screw X (Inner) 25mm 20mm Burner Aeration Screw Y (Outer)

  • Page 26: Replacement Parts List

    Replacement Parts List Replacement Parts List IMPORTANT: Only genuine authorized replacement parts should be used for servicing and repair of this appliance. Instructions supplied with parts should be followed when replacing components. For further information and servicing instructions, contact your nearest authorized service branch (contact details are as shown on reverse of front cover of this manual).
  • Page 27 Town Gas 230185 ¾” BSP F/F Adjustable. Gas Conversion Kits Gas Type to Convert to Model Nat. Gas Butane Town Gas Nat. Gas (UK) LPG (UK) RN8110G 231976 231975 231977 N/A (*) 231976 231975 Accessories 228921 Rear Roller Kit. 228800...
