Note:
Hold "0-9" digit keys to input character, the "." key to go back to the previous digit or
the "M+" key to advance to the next character.
A flashing character can be used for entering a space by pressing the 0 key for
slightly longer duration.
Tare value will only be stored with PLU data if the scale is in the NET mode. If the
container is less then the manual zero range which is set in "Technical parameters"
(default is 2% of capacity) then the scale will be Zeroed and no tare value will be
stored. To avoid this, use a larger container, reduce the zero range or use the digital
tare method.

6.4.2 ENTERING DESCRIPTION MANUALLY

The description can be up to 12 characters long and can be a mix of numbers,
symbols or letters.
During the procedure to set the description the numeric keypad will work in a similar
way to a mobile telephone. Pressing a number briefly will show the number and
holding it down will scroll through all the characters.
The numbers and characters are:
1 - / \
2 A B C
3 D E F
4 G H I
5 J K L
6 M N O
7 P Q R S
8 T U V
9 W X Y Z
0 _ [ ] Where _ is a Space (Not underscore)
The limitations of the 7 segment display sometimes make it difficult to display some
letters. The characters and the displayed symbols are:
A B C D E F G H I
A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
The characters will be stored as text so the output of the RS-232 interface will be
correct.
The numbers 1 2 3 4 5 6 7 8 9 0 will be 1234567890
Note that this method is only used where alpha-numeric data is permitted. This is
used for the Description field and the User ID number, Scale ID number in the
parameters section.
- 14 -
J K L M N O P Q R S T U V W X Y Z - / \ ( )
