Using the Accessory Rails

The monitor features accessory rails on the rear that can be used to mount optional devices, such as
the HP speaker bar, to attach to the LCD. Refer to the documentation included with the optional
device for detailed mounting instructions.
Figure 2-1

Removing the Monitor Pedestal Base

You can remove the monitor panel from the pedestal base to install the panel on a wall, a swing arm,
or other mounting fixture.
CAUTION:
power and signal cables are both disconnected. Also disconnect all USB cables connected to the
monitor.
1. Disconnect and remove the signal, power, and USB cables from the monitor.
2. Lay the monitor face down on a flat surface covered by a clean, dry cloth.
Using the Accessory Rails Feature
Before beginning to disassemble the monitor, be sure the monitor is turned off and the
Using the Accessory Rails 7
