Front Panel Controls

Table 2-1 Monitor Front Panel Controls
Control
1
2
3
4
5
NOTE: To view an OSD menu simulator, visit the HP Customer Self Repair Services Media Library
at http://www.hp.com/go/sml.
Function
Menu Opens, selects or exits the OSD menu.
Auto Adjustment/ If the OSD menu is inactive, press to activate the auto
Minus adjustment feature to optimize the screen image.
If the OSD menu is on, press to navigate backward through
the OSD menu and decrease adjustment levels.
Plus If the OSD menu is on, press to navigate forward through
the OSD menu and increase adjustment levels.
Power LED White = Fully powered.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
Power Turns the monitor on or off.
Front Panel Controls 5
