Using the Accessory Rails

The monitor features accessory rails on the rear that can be used to mount optional devices, such as
the HP speaker bar, to attach to the monitor. Refer to the documentation included with the optional
device for detailed mounting instructions.
Figure 2-6

Mounting the Monitor Panel

You can remove the monitor panel from the pedestal base to install the panel on a wall, a swing arm
(sold separately), or other mounting fixture. Four threaded mounting holes are provided on the
monitor back panel to be used for mounting purposes.
CAUTION:
power and signal cables are both disconnected.
1. Disconnect and remove the signal and power cables from the back of the monitor.
2. Lay the monitor face down on a flat surface covered by a dry, clean cloth.
Using the Accessory Rails Feature
Before beginning to disassemble the monitor, be sure the monitor is turned off and the
