PL2500SPH Owner's Manual
AERATOR Owner's Manual
PL2500SPH
U.S. PATENT #6892821

Replacement Parts

TINE REPLACEMENT
TINE BUSHING REPLACEMENTS
Replacement tip for aerating tines.
Replacement bushings for the tines
P/N 381057
P/N 380213
Part No 100383
Form No F010515C
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PL2500SPH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Billy Goat PL2500SPH

Summary of Contents for Billy Goat PL2500SPH

  • Page 1: Replacement Parts

    PL2500SPH Owner’s Manual AERATOR Owner's Manual PL2500SPH U.S. PATENT #6892821 Replacement Parts TINE REPLACEMENT TINE BUSHING REPLACEMENTS Replacement tip for aerating tines. Replacement bushings for the tines P/N 381057 P/N 380213 Part No 100383 Form No F010515C...

  • Page 2: Table Of Contents

    PL2500SPH Owner’s Manual CONTENTS SPECIFICATIONS _____________________ SAFETY INSTRUCTIONS______________ INSTRUCTION LABELS _____7 PACKING CHECKLIST & ASSEMBLY OPERATION MAINTENANCE ____________________ TROUBLE SHOOTING AND WARRANTY ___________________________________11 ILLUSTRATED PARTS & PARTS LIST 12-13 Part No 100383 Form No F010515C...

  • Page 3: Specifications

    PL2500SPH Owner’s Manual Specifications PL2500SPH Engine: cc 196cc Engine: Honda GX200 w/Gearbox Engine: Fuel Capacity 3.3 qt. (3.1 L) Engine: Oil Capacity 0.63 qt. (0.58 L) Total Unit Weight: 360# (163.3 Kg) 67.5” (1.7m) Length 32.5” (.83m) Width 41.25” (1m) Height Max.
  • Page 4 This symbol indicates that this manual and the engine manufacturer’s manual should be read carefully before assembling, operation, or servicing this equipment. ® This symbol indicates important information that will prevent damage to your BILLY GOAT Machine. This symbol indicates the engine oil level should be checked before operating this equipment.

  • Page 5: Safety Instructions

    PL2500SPH Owner’s Manual SAFETY INSTRUCTION DO NOT run this equipment indoors or in any poorly ventilated area. Refueling outdoors is recommended. DO NOT refuel this equipment while the engine is running. Allow engine to cool for at least two minutes before refueling.
  • Page 6 PL2500SPH Owner’s Manual ALWAYS keep hands and feet away from moving or rotating parts. ALWAYS check fuel lines and fittings frequently for cracks or leaks. Replace if necessary ALWAYS store fuel in approved safety containers. Warning Important DO identify and mark all fixed objects to be avoided during work, such as sprinkler heads, water valves, buried cables, or clothes line anchors, etc.

  • Page 7: Instruction Labels

    INSTRUCTION LABELS ® The labels shown below were installed on your BILLY GOAT Aerator. If any labels are damaged or missing, replace them before operating this equipment. Part numbers from the Illustrated Parts List are provided for convenience in ordering replacement labels. The correct position for each label may be determined by referring to the part numbers shown.

  • Page 8: Packing Checklist & Assembly

    PL2500SPH Owner’s Manual PACKING CHECKLIST Your Billy Goat is shipped from the factory in one carton, completely assembled. READ all safety instructions before assembling unit. TAKE CAUTION when removing the unit from the box. PUT OIL IN ENGINE BEFORE STARTING PARTS BAG &...

  • Page 9: Operation

    PL2500SPH Owner’s Manual OPERATION PARKING NEVER PARK THIS UNIT ON A SLOPE OF ANY KIND. Always keep tines in the up position when parking the unit. TINES RAISING/LOWERING The tines are raised or lowered into the ground by operating the tine engagement lever on the upper handle. Tine penetration is very dependent on surface preparation.

  • Page 10: Maintenance

    PL2500SPH Owner’s Manual MAINTENANCE ERIODIC AINTENANCE Periodic maintenance should be performed at the following intervals: Maintenance Operation Every Use (daily) Every 10 hrs Every 50 Hrs Every 100 Hrs  Inspect for loose, worn or damaged parts.  Check engine oil.

  • Page 11: Trouble Shooting And Warranty

     The machine must be taken to the dealer from whom it was purchased or to an authorized Servicing BILLY GOAT Dealer. ...

  • Page 12: Illustrated Parts & Parts List

    PL2500SPH Owner’s Manual PARTS DRAWING PL2500SPH Part No 100383 Form No F010515C...
  • Page 13 PL2500SPH Owner’s Manual PARTS LIST PL2500SPH PL2500SPH PL2500SPH ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION 381625 PREHARD ROLLER 381003 RUBBER LATCH KIT 381627 TENSION IDLER MOUNT BRACKET 8171003 WASHER 5/16" FLAT 381629 LOWER BELT TENSION BRACKET 350114 IDLER PULLEY 2.75"...
