PL25SPH Owner's Manual
AERATOR Owner's Manual
PL2500SPH
U.S. PATENT #6892821
Beginning Serial #: 020816001
Replacement Parts
TINE REPLACEMENT
TINE BUSHING REPLACEMENTS
Replacement tip for aerating tines.
Replacement bushings for the tines
P/N 381057
P/N 380213
Original Instructions
IMPORTANT- READ CAREFULLY BEFORE USE AND KEEP FOR FUTURE REFERENCE
Part No 100383
1
Form No F020816B
Advertisement
Table of Contents
Related Manuals for Billy Goat PL25SPH
Summary of Contents for Billy Goat PL25SPH
- Page 1 PL25SPH Owner’s Manual AERATOR Owner's Manual PL2500SPH U.S. PATENT #6892821 Beginning Serial #: 020816001 Replacement Parts TINE REPLACEMENT TINE BUSHING REPLACEMENTS Replacement tip for aerating tines. Replacement bushings for the tines P/N 381057 P/N 380213 Original Instructions IMPORTANT- READ CAREFULLY BEFORE USE AND KEEP FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
PL25SPH Owner’s Manual CONTENTS SPECIFICATIONS INTENDED USE INSTRUCTION LABELS PACKING CHECKLIST & ASSEMBLY OPERATION MAINTENANCE TROUBLE SHOOTING AND WARRANTY ILLUSTRATED PARTS & PARTS LIST 10-11 DECLARATION OF CONFORMITY 12-14 Part No 100383 Form No F020816B... -
Page 3: Specifications
PL25SPH Owner’s Manual SPECIFICATIONS PL2500SPH Engine: cc 196cc Engine: Honda GX200 w/Gearbox Engine: Fuel Capacity 3.3 qt. (3.1 L) Engine: Oil Capacity 0.63 qt. (0.58 L) Total Unit Weight: 360# (163.3 Kg) 67.5” (1.7m) Length 32.5” (.83m) Width 41.25” (1m) Height Max. -
Page 4: Intended Use
PL25SPH Owner’s Manual INTENDED USE AERATOR This machine is designed for aerating established lawns and large grass covered areas. The machine should not be used for any other purpose than that stated above. DO NOT OPERATE IF EXCESSIVE VIBRATION OCCURS! If excessive vibration occurs, shut engine off immediately and check for damaged or worn reel, loose reel bearing, loose engine or lodged debris. -
Page 5: Instruction Labels
INSTRUCTION LABELS ® The labels shown below were installed on your BILLY GOAT Aerator. If any labels are damaged or missing, replace them before operating this equipment. Part numbers from the Illustrated Parts List are provided for convenience in ordering replacement labels. -
Page 6: Packing Checklist & Assembly
PL25SPH Owner’s Manual PACKING CHECKLIST Your Billy Goat is shipped from the factory in one carton with the handle and cables detached. READ all safety instructions before assembling unit. TAKE CAUTION when removing the unit from the box. PUT OIL IN ENGINE BEFORE STARTING PARTS BAG &... -
Page 7: Operation
PL25SPH Owner’s Manual OPERATION STARTING ENGINE See engine manufacturer’s instructions for type and amount of oil and gasoline used. Engine must be level when checking and filling oil and gasoline. ON/OFF SWITCH: Set the On/Off Switch to the On position. -
Page 8: Maintenance
PL25SPH Owner’s Manual MAINTENANCE NOTE: Items in ( ) can be referenced in the Parts Illustration and Parts List on pages 10-11. PERIODIC MAINTENANCE Periodic maintenance should be performed at the following intervals: Maintenance Operation Every Use (daily) Every 10 hrs... -
Page 9: Trouble Shooting And Warranty
The machine must be taken to the dealer from whom it was purchased or to an authorized Servicing BILLY GOAT Dealer. ... -
Page 10: Illustrated Parts & Parts List
PL25SPH Owner’s Manual PL2500SPH PARTS DRAWING Part No 100383 Form No F020816B... - Page 11 PL25SPH Owner’s Manual PL2500SPH PARTS LIST PL2500SPH PL2500SPH ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION 381003-01 RUBBER LATCH KIT 381625 PREHARD ROLLER 8171003 WASHER 5/16" FLAT 381627 TENSION IDLER MOUNT BRACKET 350114 IDLER PULLEY 2.75" DIA 380232...
-
Page 12: Declaration Of Conformity
PL25SPH Owner’s Manual Руccкий Latviešu English Suomi Slovenščina български език Français Nederlands Čeština Slovák Ελληνικά Norsk Svenska Dansk Hrvatski Polski Türkçe Deutsch Magyar Português Română Español Italiano Lietuvių eesti keel Δήλωση συμμόρφωσης ΕΚ Deklaracja zgodności UE EC Declaration of Conformity Декларация... - Page 13 PL25SPH Owner’s Manual Directive: 2006/42/EC Irányelv: 2006/42/EC Diretiva: 2006/42/EC Директива: 2006/42/EC Οδηγία: Директива: 2006/42/EC 2006/42/EC Směrnice č. 2006/42/EC Direktiva: 2006/42/EC Directiva: 2006/42/EC Direktiv: 2006/42/EF Direttiva: 2006/42/EF Direktiva: 2006/42/EF Richtlinie: 2006/42/EG Direktyva: 2006/42/EG Smernica: 2006/42/EG Direktīva: Directriz: 2006/42/EC 2006/42/EC Direktiv: 2006/42/EC Direktiiviga: 2006/42/EÜ...
- Page 14 PL25SPH Owner’s Manual Miejsce produkcji / Osoba odpowiedzialna za Manufacturing Place / Keeper of Documentation Τόπος κατασκευής / Υπεύθυνος τήρησης αρχείων Място на производство / Архивар przechowywanie dokumentów τεκμηρίωσης Místo výroby / Držitel dokumentace Gyártás helye / A dokumentáció őrzője Local de Fabrico / Responsável pela Documentação...
