- Page 1 TPC-1240 RISC-based operator interface terminal with 12.1” flat panel display Users Manual...
- Page 2 Acknowledgements TPC-1240 is a trademark of Advantech Co., Ltd. IBM, PC/AT, and PS/2 are trademarks of International Business Machines Corporation. MS- DOS and Windows CE are trademarks of Microsoft Corporation. iCava is a trademark of Avamax Incorporated.All other brand and product names...
- Page 3 FCC Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence when the equipment is operated in a commercial environment.
- Page 4 Packing List In the whole set of TPC-1240 there are items as listed below: • TPC-1240T-CE (or TPC-1240T-LNX) x 1 unit; the Windows CE (or Linux) operating system image is built in the flash memory on board. • Accessory kit which includes:...
- Page 5 Safety Instructions 1. Read these safety instructions carefully. 2. Keep this User's Manual for later reference. 3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
- Page 6 - Wenn das Gerät deutliche Anzeichen eines Defektes aufweist. Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70 dB(A) oder weiger. DISCLAIMER: This set of instructions is given according to IEC704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. TPC-1240 User’s Manual...
-
Page 7: Table Of Contents
Table 3.1: CPC-1110 main board connector/jumper list .. 14 Table 3.2: Connector pin assignments ......14 TPC-1240 I/O board............15 Table 3.3: TPC-1240 I/O board connector/jumper list ..15 Table 3.4: TPC-1240 COM1/COM3 (RS-232) serial ports... Table 3.5: TPC-1240 COM2 (auto flow control RS-485) se- rial port 16 Table 3.6: LCD inverter connector ........ - Page 8 Chapter 4 Windows CE in the TPC-1240 .....19 Introduction ..............20 Figure 4.1: Windows CE on TPC-1240 ......20 TPC Utilities..............21 Figure 4.2: Soft-keyboard ........... 21 Figure 4.3: TPC Configurator ..........22 Figure 4.4: TPC Configurator ..........23 Figure 4.5: Calibrating Tapping location ......23 Figure 4.6: Screen for calibration........
- Page 9 Fuse replacement............. 52 Figure 7.4: Replace the fuse..........52 Appendix A Fuse Specifications .........53 Supported Input Timing Modes ........54 Appendix B Registry searching sequence of TPC-1240...55 Supported Input Timing Modes ........56 Figure B.1: Windows CE registry searching algorithm flow- chart56...
-
Page 11: Chapter 1 General Information
General Information This chapter gives background information on the TPC-1240. Sections include: • Introduction • Specifications • LCD Specifications • Touchscreen specifications • Power • I/O ports • Mounting • Exploded diagram • Dimensions and cutout Chapter 1 General Information... -
Page 12: Introduction
Please refer to chapter 4 for details about Windows CE inside, and to chapter 5 for details about Linux. - Slim but robust: the TPC-1240 is very thin (50 mm thickness) and lightweight (2.2 kg). This makes it the best solution for those applica- tions that are tough in space or weak structural support. -
Page 13: Specifications
- The primary storage device is the 16 MB built-in flash memory. The default Windows CE or Linux operating system is in this device. - The TPC-1240 provides one CompactFlash card slot. This slot is for the storage of variety of Windows CE/Linux-based application pro- grams. -
Page 14: Lcd Specifications
Maximum Colors 256k Pixel pitch (WxH, mm) 0.31 x 0.31 Viewing angle Luminance (cd/m Contrast ratio 150 minimum Operating temperature ( 0-50 (ambient) VR control Brightness adjustable Backlight 2 CCFL Backlight MTTF 50,000 hours Table 1.1: LCD specifications TPC-1240 User’s Manual... -
Page 15: Touchscreen Specifications
In spite of the stated input voltage rating, the TPC-1240 can operate using 18 ~ 30 V 1.6 I/O Ports Arrangement The TPC-1240 has 3 serial ports, 1 RJ-45 LAN port. The arrangement of these ports is shown in Figure 1.1 Chapter 1 General Information... -
Page 16: Mounting
Make sure the waterproof gasket is in position before install the TPC-1240 to the panel opening. 2.Install the TPC-1240 to the panel opening. 3.Find the eight clamps and eight long screws in the accessory pack. Hook those clamps to those holes around the four sides of the bezel. -
Page 17: Exploded Diagram
1.8 Exploded diagram Figure 1.3: Exploded diagram Chapter 1 General Information... -
Page 18: Dimensions And Cutout
1.9 Dimensions and cutout - Weight: 2.2 kg (without HDD) - Dimension: 311 x 237 x 50 mm (W x H x D) - Cutout: 302 x 228 mm (suggested) Figure 1.4: Dimensions and cutout TPC-1240 User’s Manual... -
Page 19: Chapter 2 System Quick Starting
System Quick Starting This chapter provides a brief explanation for operating the TPC-1240. Chapter 2 System Quick Starting... -
Page 20: Unpacking And Powering Up
Chapter 2 System Quick Starting 2.1 Unpacking and Powering up Step 1 Unpack the TPC-1240 from its packaging. Please check the packing list at the beginning of this manual. Figure 2.1: Opening the box Cushions Accessory Box (P/N: 2130201590) (P/N: 2110002150)
