2. INTRODUCTION
2.1
Features
•
DMX512/1990 Standard
•
Controls 24 intelligent lights of up to 16 channels, totally 384 channels
•
30 banks, each with 8 scenes; 6 chase, each with up to 240 scenes
•
Record up to 6 chases with fade time and speeds
•
16 sliders for direct control of channels
•
MIDI control over banks, chases and blackout
•
Built-in microphone for music mode
•
Auto mode program controlled by fade time sliders
•
DMX in/out: 3 pin XLR
•
LED gooseneck lamp
•
Plastic end housing
2.2
General Overview
The Controller is a universal intelligent lighting controller. It allows the control of 24
fixtures composed of 16 channels each and up to 240 programmable scenes. Six chase
banks can contain up to 240 steps composed of the saved scenes and in any order.
Programs can be triggered by music, midi,automatically or manually. All chases can be
executed at the same time.
On the surface you will find various programming tools such as 16 universal channel
sliders, quick access scanner and scene buttons, and an LED display indicator for easier
navigation of controls and menu functions.
2.3 Nifty, Spiffy Diagram (front)
4
SNOKONTROL Manual Rev B.
Page 6
3
2
1
10
9
5 13 14 15 6 11 12
Copyright © 2010-2013 Blizzard Lighting, LLC.
18 7
8
16 17
ALL RIGHTS RESERVED
