Jiva TP/LT- 5600/5800 Series
Touch Terminal
User's Manual
Rev. Original
FCC Notes:
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions manual, may cause interference
to radio communications. It has been tested and found to comply with limits for a Class
A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to
provide reasonable protection against interference when operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take whatever
measures to correct the interference.
Warranty Limits:
Warranty terminates automatically when any person other than the authorized
technicians opens the machine. The user should consult his/her dealer for the problem
happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or
hazard caused by improper application.
About This Manual:
Posiflex has made every effort for the accuracy of the content in this manual. However,
Posiflex will assume no liability for any technical inaccuracies or editorial or other
errors or omissions contained herein, nor for direct, indirect, incidental, consequential
or otherwise damages, including without limitation loss of data or profits, resulting
from the furnishing, performance, or use of this material.
This information is provided "as is" and Posiflex Inc. expressly disclaims any
warranties, express, implied or statutory, including without limitation implied
warranties of merchantability or fitness for particular purpose, good title and against
infringement.
The information in this manual contains only essential hardware concerns for general
user and is subject to change without notice. Posiflex reserves the right to alter product
designs, layouts or drivers without notification. The system integrator shall provide
applicative notices and arrangement for special options utilizing this product. The user
may find the most up to date information of the hardware from web sites:
http://www.posiflex.com or http://www.posiflex.com.tw
All data should be backed-up prior to the installation of any drive unit or storage
peripheral. Posiflex will not be responsible for any loss of data resulting from the use,
disuse or misuse of this or any other Posiflex product.
All rights are strictly reserved. No part of this documentation may be reproduced,
stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, or otherwise, without prior express written consent from
Posiflex Inc. the publisher of this documentation.
© Copyright Posiflex Inc. 2005
All brand and product names and trademarks are the property of their respective holders.
Part 1
P/N: 16280902110

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jiva LT-5600 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for POSIFLEX Jiva LT-5600 Series

  • Page 1 About This Manual: Posiflex has made every effort for the accuracy of the content in this manual. However, Posiflex will assume no liability for any technical inaccuracies or editorial or other errors or omissions contained herein, nor for direct, indirect, incidental, consequential or otherwise damages, including without limitation loss of data or profits, resulting from the furnishing, performance, or use of this material.
  • Page 2 ALERT TO OUR HONORABLE CUSTOMERS: l Please always read thoroughly all the instructions and documents delivered with the product before you do anything about it. Don’t take any premature action before you have a full understanding of the consequences. l This product contains inside a Lithium battery and maybe also a sealed type Lead acid battery if the UPS battery option is ordered.
  • Page 3: Brief Introduction

    The User’ s Manual The purpose of this manual is to guide the user in the initial installation and general use of the Posiflex Jiva TP/LT-5600 series and Jiva TP/LT-5800 series of POS terminals. It does not explain any application software that may be supplied with it.
  • Page 4 Long life touch panel that endures 10 million touches at same spot (for Jiva TP only) Spill proof water resistant structure allowing easy cleaning Easy maintenance construction Various I/O ports supported, including: 1. one PS/2 KB port 2. one PS/2 mouse port 3.
  • Page 5 MSR or smart card reader and finger print sensor or iButton reader ² Security upgrade kit SD200 covering options of USB interface MSR or optical scan type finger reader ² Bar code card reader BC-100U Integrated rear top mount LCD customer display PD-302 2 in 1 cash drawer control cable (CCBLA-238) USB interface external slim type CD ROM drive UPS battery...
  • Page 6: Opening Cable Cover

    INSTALLATION GUIDES CAUTION: Before any installation or cable connection to the set, please always make certain that the system is turned off and the external power source to the set is removed to prevent electric hazard! Never touch any metal pin in the connectors or circuits to avoid high voltage hazard or electrostatic discharge damage unless the operator is well grounded.
  • Page 7: Disconnecting Cables

    DISCONNECTING CABLES After removal of the cable cover, the connector area will be accessible then. Please disconnect every cable before separation of main unit and the adjustable stand assembly. When later the main unit and stand assembly are to be re-assembled for application, please connect all required cables to the appropriate connectors.
  • Page 8: Installing Ups Battery

    CASH DRAWER The Jiva series is able to control the printer (direct) drive type Posiflex cash drawers. Among them, it is recommended that the Posiflex CR- 4000 or CR-4210 be used since the terminal has been designed to compliment this cash drawer both mechanically and electrically.
  • Page 9: Routing The Cables

    ROUTING THE CABLES Fix this End of the Cover First Route Cables under the Cover Connect this End to Main Unit This End to Other Devices Place all the cables required for connections to the Jiva TP/LT-5600 or Jiva TP/LT-5800 except those for special application purposes into the cable passage.
  • Page 10 Posiflex wireless connection driver elements. The driver can be found together in delivery of the wireless printer or the Posiflex Product Information CD of version 1.9 or above, or please find it on our web http://www.posiflex.com/ or http://www.posiflex.com.tw...
  • Page 11: Joining Main Unit And Stand

    JOINING MAIN UNIT AND STAND Matching Pegs Matching Holes Round Part Slot Part Removal Hollow Match the matching pegs on the back of the main unit against the matching holes on the stand. First aim the matching pegs toward the upper round part of the hole and make sure that all pegs are inside the holes.
  • Page 12: Location For Installation

    assembly. The stand assembly is not engaged in wall mount operation. Wall Mount Bracket Matching Holes Show Screw this Holes side out. LOCATION FOR INSTALLATION As the stand assembly is not involved in wall mount installation, the space required for wall mount application will take only the main unit into consideration.
  • Page 13: Operating System Installation

    For the Jiva TP/LT-5800 preloaded with Windows XP Pro or WEPOS on HDD, Posiflex provides recovery CD delivered with the touch terminal for the preloaded operating system. The System Integrator shall take care of software restoration after OS recovered. A Posiflex supplied USB interface CDROM drive or the internal type IDE interface CDROM drive with the cable kit mentioned earlier will be required for such action.
  • Page 14: Using The Touch Pos

    USING THE TOUCH POS APPLICATION ENVIRONMENT It is very important that you check the following operation guidelines: Ventilation This terminal must NOT be operated in an environment with restricted ventilation. The installation should be such that there is at least 25mm air clearance around any top or side ventilation holes.
  • Page 15: Power On/Off

    Emergency treatment: The battery is constructed maintenance free and leakproof. It is well protected in Jiva system as long as the ambient temperature remains below 30°C and the ventilation of the Jiva system remains free. However, should any accident happen and the sulfuric acid from the battery spills on skin or clothing, wash immediately with water.
  • Page 16: Automatic Power On

    In preloaded Windows, “Posiflex Power Switch Manager” in “Posiflex Tools” in the Program Files helps managing these functions. Software Support Features The Jiva series provides a software power off command for application program maneuvers.
  • Page 17: Display Settings

    This port supports either mirror mode (identical image) or extended mode dual display function for Win98 or WinXP. To support the DC power to these Posiflex monitor, use the DC adaptor to connect into the monitor or Part 17...
  • Page 18: System Protection

    SYSTEM PROTECTION In the Posiflex POS system delivered with preloaded OS, there is a function built in for system protection. A screen as below will pop up for a short period of time in operation system booting up stage.
  • Page 19: System Monitor

    of the system to engage this function if there is no specific instruction from your system integrator. Press the three key combination of “Ctrl” + “Alt” + “F12” at the above screen or press the key on programmable keyboard per your system integrator’s arrangement.
  • Page 20 A program named “Posiflex Touch Terminal Manager” is installed in the preloaded Windows system with a PS/2 interface touch panel controller. This program can also be obtained by download from the POSIFLEX web site. This program can be engaged in the program group “Posiflex Tools”...
