TM/LM-5011 & TM/LM-5011P
POS Monitor
User Manual
Package Contents
10.1" TM/LM-5011 or TM/LM-5011P POS Monitor....................(x 1)
Mounting Kits ...............................................................................(x 1)
Date
2024/01/16
2024/06/03
FCC NOTES
This system meets industry & government requirements and applicable standards. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions manual, may cause interference to radio communications. It has been tested
and found to comply with limits for a Class A digital device pursuant to subpart B of Part 15 of
FCC Rules, which are designed to provide reasonable protection against interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely
to cause interference in which case the user at his own expense will be required to take whatever
measures to correct the interference.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
CE CLASS A WARNING
This equipment is compliant with Class A of CISPR 32. In a residential environment this
equipment may cause radio interference.
AVERTISSEMENT CE CLASSE A
Cet équipement est conforme à la classe A de CISPR 32. Dans un environnement résidentiel, cet
équipement peut provoquer des interférences radio.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the
authorized technicians. The user should consult his/her dealer for the problem happening.
Warranty voids if the user does not follow the instructions in application of this merchandise. The
manufacturer is by no means responsible for any damage or hazard caused by improper application.
Revision History
Version
A0
B0
The mechanical part has modified the
hinge neck cover which add two screws
to fix. (Only for TM/LM-5011P-RT)
1
Description
For Preliminary Release
TM/LM-5011(P) Ver. B0

Advertisement

loading
Need help?

Need help?

Do you have a question about the LM-5011 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POSIFLEX LM-5011

  • Page 1 TM/LM-5011 & TM/LM-5011P POS Monitor User Manual Package Contents  10.1” TM/LM-5011 or TM/LM-5011P POS Monitor……………..…(x 1)  Mounting Kits ………………..…............(x 1) Revision History Date Version Description 2024/01/16 For Preliminary Release 2024/06/03 The mechanical part has modified the hinge neck cover which add two screws to fix.
  • Page 2 LIMITES DE GARANTIE La garantie prend fin automatiquement lorsque la machine est ouverte par une personne autre que les techniciens autorisés. L'utilisateur doit consulter son revendeur pour le problème qui se produit. La garantie s'annule si l'utilisateur ne suit pas les instructions d'application de cette marchandise. Le fabricant n'est en aucun cas responsable de tout dommage ou danger causé...
  • Page 3 Views of TM/LM-5011 Front View Camera (Optional) 10.1” LCD Panel/P-CAP Touch Panel The Mark which indicating the scanning area of the barcode scanner Rear View 40-Pin eDP Cable Plastic Hinge Cover Side Attachment Cover Barcode Scanner Window (Optional)
  • Page 4 Views of TM/LM-5011P Front View Camera (Optional) 10.1” LCD Panel/P-CAP Touch Panel The Mark which indicating the scanning area of the barcode scanner (Optional) Rear View LM/TM-5011P-RT LM/TM-5011P-ZT Plastic Hinge Cover Side Attachment Cover Side Attachment Cover VGA Cable for RT 40-Pin eDP Cable for Series POS Terminal ZT Series POS Terminal...
  • Page 5 Mounting your Monitor to ZT-series POS Terminals The following instructions are provided to help you mount your TM/LM monitor to Posiflex ZT-series POS terminals. During installation, please ensure the terminal is properly turned off and disconnected from the power sources to avoid potential hazards.
  • Page 6 Rotate the screen to the upright position like below pictures. There is a latch inside cable exit on the rear side of the POS terminal. Push the latch with the thumb of the left hand, and then the touch monitor will release automatically.
  • Page 7 Open the touch monitor with two hands, and then you can do the maintenance work. Remove the attachment cover on the top side by pressing the inner hook on both sides. Press. Fix the 2 monitor with two thumbscrews, and then connect the eDP cable to the ZT series main board.
  • Page 8 Mounting your Monitor to RT-series POS Terminals (TM/LM-5011P-RT) The following instructions are provided to help you mount your TM/LM monitor to Posiflex RT-series POS terminals. During installation, please ensure the terminal is properly turned off and disconnected from the power sources to avoid potential hazards.
  • Page 9 Remove the plastic hinge cover by both hands. Lift the dummy cover a little and then remove it. Remove. Hold down the release lever at the bottom of the RT system back cover and then pulling the cover outwards.
  • Page 10 Remove the 2 display dummy cover. Find the VGA connector on the main board shown as below picture. Connect the VGA cable to the main board and then fix the TM/LM to the RT series POS terminal with two #6/32 screws...
  • Page 11 Place back the system back cover from top side to close the sytem compartment of RT-series terminal.u Install the dummy cover to the hinge bracket. Make sure the cover is hooked on the hinge bracket like below picture. Hook.
  • Page 12 Close the plastic hinge cover bracket. Fix the two original countersunk head screws on both sides of the hinge cover. Tilt the monitor screen to your desired angle. While setting up the tilting adjustment, be careful NOT to press on the LCD panel.
  • Page 13 Identifying your Monitor as Secondary Touchscreen Monitor in Extended Mode In the following section the related descriptions will be offered to help you set up TM series as the extended monitor when you attempt to extend the desktop across multiple monitors For TM-5011/5011P Model with P-CAP Touchscreen If your monitors are TM-5011/5011P models, you may configure the display settings from Control Panel in Microsoft Windows to identify the monitor as...
  • Page 14: Installing Drivers

    To start up the monitor, please make sure that the monitor is well connected to POS terminals and electricity is supplied to the monitor through POS terminal. Installing Drivers Please visit Posiflex official website to download and install the related drivers. (https://download.posiflex.com/en-global/Download/index/driver/POS- Monitor/TM-5011) Setting up Display Resolution for Your Monitor The below chart defines the list of recommended display settings for TM/LM monitor.
  • Page 15: Specification

    Optional, 2D barcode scanner on rear cover Camera TM/LM-5011: Optional, 1MP wide angle camera module TM/LM-5011P: Optional, 5MP wide angle camera module Mechanical Dimension TM/LM-5011: 239.2 x 171.9 x 26.3 mm (WxDxH) TM/LM-5011P: 163.9 x 255.2 x 26.3 mm (WxDxH)
  • Page 16: Outline Dimension

    Net Weight 1 kg Mounting VESA mounting hole 75 x 75 Outline Dimension TM/LM-5011...
  • Page 17 TM/LM-5011P ※ The product information and specifications are subject to change without prior notice.

This manual is also suitable for:

Tm-5011Lm-5011pTm-5011p
