TM/LM-5011LC/PC
POS Monitor
User Manual
Package Contents
10.1" TM/LM-5011LC or TM/LM-5011PC POS Monitor..............(x 1)
Type-C Cable..................................................................(x 1)
Mounting Kits ...............................................................................(x 1)
Date
2024/09/16
FCC NOTES
This system meets industry & government requirements and applicable standards. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions manual, may cause interference to radio communications. It has been tested
and found to comply with limits for a Class A digital device pursuant to subpart B of Part 15 of
FCC Rules, which are designed to provide reasonable protection against interference when
operated in a commercial environment. Operation of this equipment in a residential area is likely
to cause interference in which case the user at his own expense will be required to take whatever
measures to correct the interference.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
CE CLASS A WARNING
This equipment is compliant with Class A of CISPR 32. In a residential environment this
equipment may cause radio interference.
AVERTISSEMENT CE CLASSE A
Cet équipement est conforme à la classe A de CISPR 32. Dans un environnement résidentiel, cet
équipement peut provoquer des interférences radio.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the
authorized technicians. The user should consult his/her dealer for the problem happening.
Warranty voids if the user does not follow the instructions in application of this merchandise. The
manufacturer is by no means responsible for any damage or hazard caused by improper application.
Revision History
Version
A0
1
Description
For Preliminary Release
TM/LM-5011LC/PC Ver. A0

Advertisement

loading
Need help?

Need help?

Do you have a question about the TM-5011LC and is the answer not in the manual?

Questions and answers

Summary of Contents for POSIFLEX TM-5011LC

  • Page 1 TM/LM-5011LC/PC POS Monitor User Manual Package Contents  10.1” TM/LM-5011LC or TM/LM-5011PC POS Monitor………..…(x 1)  Type-C Cable…………………………………………………………(x 1)  Mounting Kits ………………..…............(x 1) Revision History Date Version Description 2024/09/16 For Preliminary Release FCC NOTES This system meets industry & government requirements and applicable standards. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause interference to radio communications.
  • Page 2 LIMITES DE GARANTIE La garantie prend fin automatiquement lorsque la machine est ouverte par une personne autre que les techniciens autorisés. L'utilisateur doit consulter son revendeur pour le problème qui se produit. La garantie s'annule si l'utilisateur ne suit pas les instructions d'application de cette marchandise. Le fabricant n'est en aucun cas responsable de tout dommage ou danger causé...
  • Page 3 Views of TM/LM-5011LC Front View Camera (Optional) 10.1” LCD Panel/P-CAP Touch Panel The Mark which indicating the scanning area of the barcode scanner (If there is a barcode scanner) Rear View Type-C Connector Side Attachment Cover Barcode Scanner Window (Optional)
  • Page 4 Views of TM/LM-5011PC Front View Camera (Optional) 10.1” LCD Panel/ P-CAP Touch Panel The Mark which indicating the scanning area of the barcode scanner (If there is a barcode scanner) Rear View Side Attachment Cover Type-C Connector Barcode Scanner Window (Optional)
  • Page 5 TM/LM-5011LC is landscape mode; TM/LM-5011PC is portrait mode. It takes TM/LM-5011LC for example in below installation guide. Note: Please use the type-C cable certified/provided by Posiflex. Please DO NOT use the cables from other unknown sources. Remove the cable cover.
  • Page 6 Remove the plastic rear cover. Remove. Connect the USB type-C cable to the USB type-C port on the top side of the main board. Install the hinge with five screws, being careful not to press the cables.
  • Page 7 Route the cable like the below picture and then close the plastic rear cover back to the POS terminal. For BT-3015/3016/8015/8016 (Windows-based) POS terminal, there is only one USB type-C cable. For BT-2015/2016 (Android-based) POS terminal, there are two cables: one USB type-C cable and one 9-pin NFC cable. 9-pin NFC cable USB type-C cable...
  • Page 8 Fix the plastic rear cover with one original M2 screw. Pass the USB type-C cable and the 9-pin NFC cable (if there is) through the cable exit of the hinge bracket, and then install the hinge bracket with four M4 screws. Pass through the cable and install.
  • Page 9 Insert the four thumbscrews into the four screw holes of the hinge bracket. 10. Connect the USB type-C cable and the 9-pin NFC cable (if there is) to the TM/LM-5011PC or TM/LM-5011LC.
  • Page 10 11. Fix the four thumbscrews on the rear side of the 2 display. 12. Installation completed.
  • Page 11 For TM-5011LC/PC Model with P-CAP Touchscreen If your monitors are TM-5011LC/PC models, you may configure the display settings from Control Panel in Microsoft Windows to identify the monitor as the secondary touchscreen monitor. Please go through the below steps to complete configuration.
  • Page 12: Installing Drivers

    POS terminals and electricity is supplied to the monitor through POS terminal. Installing Drivers Please visit Posiflex official website to download and install the related drivers. (https://www.posiflex.com/document/driver-and-utility/?pmid=156,173&pid=598) Setting up Display Resolution for Your Monitor The below chart defines the list of recommended display settings for TM/LM monitor.
  • Page 13: Specification

    To do the further setting of the scanner engine, please find the relevant user manual on Posiflex Global Website, (https://www.posiflex.com/document/user- manual/?pmid=156,173&pid=598) or contact the service team for technical support. Specification TM/LM-5011 Display LCD Panel 10.1" TFT LCD Resolution 1280(H) x 800 (V) Active Area 216.96mm (H) x 135.60mm (V)
  • Page 14 Outline Dimension TM/LM-5011LC...
  • Page 15 TM/LM-5011PC ※ The product information and specifications are subject to change without prior notice. Manufacturer: Posiflex Technology Inc. 4F-8F, No. 23, Datong St., Tucheng Dist., New Taipei City 236044, Taiwan Tel : +886 2 2268 5577 製造商資訊 振樺電子股份有限公司 新北市土城區大同街 23 號 4 樓~8 樓...
