Building and Operating Instructions Arcus V-Tail EDF
Page
Dear customer,
Congratulations on your choice of a factory-assembled mo-
2
del aircraft from the robbe
2
Modellsport range. Many thanks for placing your trust in us.
2
2
The model can be ready for the air when you have completed
3
just a few simple procedures.
3
Please read right through these instructions and the separate
3
information sheets before attempting to assemble and fly the
3
model, as this will make it much easier to complete the tasks
4, 5
required.
5
6
Please study the illustrations and the brief instructions
6
to obtain a clear understanding of the individual stages of
6
construction. All parts must be trial-fitted "dry" (without glue)
before you reach for the glue. Assign the individual compon-
7
ents to the various stages of assembly.
7
8
All directions, such as "right-hand", are as seen from the tail
8
of the model, looking forward.
8
8
We constantly strive to update our products to reflect the la-
8
test developments. You can find details of technical improve-
8
ments and revised documentation on the Internet by calling
8
up the appropriate product description at our website: www.
8
robbe.com.
8
8
The model
8
Not an everyday model; not just like all the others!
8
That's the Arcus V-tail EDF.
9
A compact model glider with the characteristic sound of an
9
EDF model jet. The model is equally suitable for the expe-
10
rienced pilot as well as the advanced beginner who is looking
10
for an EDF trainer, or simply fancies flying something rather
different for once.
The design and look of the Arcus V-Tail EDF are just as ex-
clusive as its power system.
The model can also be fitted with an optional rudder servo.
Specification:
Wing loading approx.:
Length approx.:
Total surface area approx.:
All-up weight approx.:
Wingspan approx.:
RC functions:
Elevator, ailerons, throttle
Optional: Rudder
Essential accessories:
ROXXY
POWER ZY 3S 1300mAh 30C
®
T6J-R2006GS 2.4 GHz FHSS
T-socket pack of 10
Recommended accessories:
Charge lead, T-plug
POWER PEAK
A4 EQ-LCD 230V/12V
®
Optional:
1x Servo 8.1 g
Set contents:
• EPO foam fuselage, tail and wing with applied decals
• Finished canopy
• Control surface linkage hardware pack
• Assembled Ø 50 mm Fan unit with Brushless-Motor and
robbe E-COLINE controller
• 3 factory-installed robbe E-COLINE 8G servos
• Multi-lingual illustrated assembly instructions
No. 2592
33.3 g/dm2
770 mm
15 dm2
500 g
1400 mm
6913
F4100
8895
8881
8560
8975
