9. Technical Specifications

Laser Wavelength
Laser Classification
Maximum Power Output
Accuracy
Interior Range
Power Supply
Battery Life
Dimensions
Weight
Working Temperature
Center screw thread
Rotation Speed
IP Protection Class
10
650nm±10nm
Class IIIa
5mW
±1/8"/30 ft. (±0.3mm/m)
Up to 200 ft. (60m) diameter depending
upon light conditions
4 "AA" alkaline batteries (included)
Approx. battery life 25 hours continuous use
4.75" x 4.75" x 6.125"
(120 x 120 x 156mm)
1.35 lbs (0.6Kg)
14°F to 113°F (-10°C to +45°C)
5/8" – 11
0-600 rpm
43
