5. Location of Part/Components
Base with Tripod
Thread and
Wall-Mounting
Bracket
1 - Vertical (plumb)
Vial "Z"
"X" Leveling Screw
©2010 Johnson Level & Tool - Rev. 1
Rotary Head
90º Split Beam
Output Window
Rotating Beam
Output Window
2 - Horizontal
(level) Vial "X"
and "Y"
"Y" Leveling
Screw
On/Off Switch and
Variable Speed
Control Knob
"Z" Leveling Screw
5
