- Page 1 Moxa ToughNet Switch TN-5516/5518 Series Layer 2 M12 managed 16/16+2G-port Ethernet switches Hardware Installation Guide First Edition, October 2009 © 2009 Moxa Inc. All rights reserved. Reproduction without permission is prohibited. P/N: 1802055160011...
-
Page 2: Package Checklist
Overview The ToughNet TN-5516/5518 series M12 managed Ethernet switches are designed for industrial applications in harsh environments. The TN series switches use M12 and other circular connectors to ensure tight, robust connections, and guarantee reliable operation against environmental disturbances, such as vibration and shock. The wide selection of 12/24/36/48 VDC, 72/96/110 VDC, or 110/220 VDC/VAC dual redundant power supplies increases the reliability of your communications. -
Page 3: Recommended Optional Accessories
IEEE 1588 PTP (Precision Time Protocol) for the precise time synchronization of networks. DHCP Option 82 for IP address assignment with different policies. Modbus/TCP industrial Ethernet protocol. Turbo Ring, Turbo Chain,and RSTP/STP (IEEE802.1w/D). IGMP Snooping and GMRP for filtering multicast traffic from industrial Ethernet protocols. - Page 4 M12A-5P-IP68: Field-installable M12 A-coded screw-in connector, female 5-pin, IP68-rated. A-CAP-M12F-MIP67-PAK04: Caps for M12 D-coded 4-pin male connectors, metal and IP67-rated. Four pieces in one pack. DK-DC50131: DIN-Rail mounting kit, 50 x 131 mm. TN-5516 Panel Layouts Top View 8 9 10 11 12 Front View Botton View...
- Page 5 10. FAULT LED. 11. MSTR/HEAD LED: for ring master or chain head. 12. CPLR/TAIL LED: for ring coupler or chain tail. 13. TP port’s 10/100 Mbps LED. 14. 10/100BaseT(X) port (female 4-pin shielded M12 connector with D coding). 15. Waterproof vent. 16.
- Page 6 3 Rotary switches and protective cover with Model name. Screw holes for panel mounting kit. Console port. Grounding screw. Relay output port. Power input voltage range indication. Power input port (male 5-pin shielded M23 connector). PWR1 LED: for power input 1. PWR2 LED: for power input 2.
-
Page 7: Mounting Dimensions (Unit = Mm)
Mounting Dimensions (unit = mm) TN-5516 Series — 6 —... -
Page 8: Panel/Wall Mounting
TN-5518 Series Panel/Wall Mounting STEP 1: Mounting the TN-5516/5518 to a wall requires 4 screws. Use the ToughNet switch as a guide to mark the correct positions of the 4 screws. STEP 2: Use the 4 screws in the panel mounting kit. If you 6.0 - 7.0 mm would like to use your own screws, make sure the screw head is between 6.0 mm and 7.0 mm in... -
Page 9: Din-Rail Mounting (Optional)
STEP 3: Once the screws are fixed in the wall, hang the ToughNet switch on the 4 screws through the large opening of the keyhole-shaped apertures, and then slide the switch downwards. Tighten the four screws for added stability. NOTE To provide greater protection from vibrations and shocks, use screws with shaft diameter between 6.0 mm and 7.0 mm, and fix the ToughNet switch onto the wall directly through the large... -
Page 10: Wiring Requirements
To remove the Moxa ToughNet Switch from the DIN-Rail, use a screwdriver to pull out the two spring-loaded brackets from the bottom until they are fixed in the “locked” position. Then reverse Step 3 and 4 above. DIN-Rail Wiring Requirements WARNING Turn the power off before disconnecting modules or wires. -
Page 11: Connecting The Power Supplies
Please read and follow these guidelines: Use separate paths to route wiring for power and devices. If power wiring and device wiring paths must cross, make sure the wires are perpendicular at the intersection point. NOTE: Do not run signal or communications wiring and power wiring through the same wire conduit. - Page 12 Pinouts for the power input port on the TN-5516/5518. Pinouts for the power input port on the TN-5516/5518. Description Usage Connect “PWR1 Live / DC +” to the Live terminal when using an AC power source or PWR1 Live / DC + to the positive (+) terminal when using a DC power source.
-
Page 13: Connecting The Relay Outputs
Connecting the Relay Outputs Each TN-5516/5518 switch has two sets of relay outputs—relay output 1 and relay output 2.The M12 A-coded 5-pin male connector on the TN-5516/5518 front panel is used for the two relay outputs. Use a power cord with an M12 A-coded 5-pin female connector to connect the relay contacts. - Page 14 Pinouts for the RJ45 (8-pin) Port RJ45 (8-Pin) MDI Port Pinouts MDI-X Port Pinouts Signal Signal Tx + Rx + Tx - Rx - Rx + Tx + Rx - Tx - M12 (4-pin, M) to M12 (4-pin, M) Cross-Over Cable Wiring Cross-Over Cable Wiring M12 (4-pin, M) to M12 (4-pin, M) Straight-Trough Cable Wiring Straight-through Cable Wiring...
- Page 15 10/100/1000BaseT(X) Ethernet Port Connection The TN-5518-2GTX models have two Gigabit Ethernet ports with RJ45-type circular connectors. The 10/100/1000BaseT(X) ports located on the bottom of the TN-5518 are used for connecting Ethernet-enabled devices. These two ports support standard Ethernet cables with RJ45 connectors; however, they will not be vibration or water-proof.
-
Page 16: Bypass Relay Function
NOTE 1. “Hardware-based IP configuration” only supports IPv4 address settings. 2. “Hardware-based IP configuration” is enabled only when the 3 rotary switches are set to values ranging from 001 to 254. The ToughNet switch’s IP address will be configured as “192.168.127.xxx”, where “xxx”... -
Page 17: Led Indicators
With the maximum segment length of category 5 twisted-pair cable being 100 meters, cable length must be considered when designing a network that utilizes this function. For example, the total length of the cables from Switch A to B and from B to C must be no more than 100 meters. This way, if the two adjacent nodes (switch B and C for example) encounter a power failure, there will be no stoppage, provided that the total length of the cables A-to-B, B-to-C, and C-to-D are no more than 100 meters. -
Page 18: Specifications
TP port’s 10 Mbps link is inactive. TP port’s 100 Mbps link is active. GREEN Blinking Data is being transmitted at 100 Mbps. TP port’s 100 Mbps link is inactive. TP port’s 10 or 100 Mbps link is active. AMBER Blinking Data is being transmitted at 10 or 100 Mbps. - Page 19 Console Port M12 A-coding 5-pin male connector System LED Indicators PWR1, PWR2, FAULT, MSTR/HEAD, CPLR/TAIL Port LED Indicators 10/100M (fast Ethernet port), 10/100/1000M (Gigabit Ethernet port) Alarm Contact Two relay outputs in one M12 A-coding 5-pin male connector with current carrying capacity of 3 A @ 30 VDC or 3 A @ 240 VAC Rotary Switches For setting the last 3 digits of the IP address...
- Page 20 Road Traffic NEMA TS2 (Pending), e-Mark (Pending) FCC Part 15, CISPR (EN55022) class A EN61000-4-2 (ESD), level 3 EN61000-4-3 (RS), level 4 EN61000-4-4 (EFT), level 3 EN61000-4-5 (Surge), level 3 EN61000-4-6 (CS), level 3 EN61000-4-8 EN61000-4-11 EN61000-4-12 Shock IEC61373 Freefall IEC60068-2-32 Vibration IEC61373...
