SmartNode 4400 Series Getting Started Guide

Load a new application image (SmartWare) via the serial link

The Bootloader supports the 'X-Modem' and 'Y-Modem' protocols to download application images via the
serial link of the console. Do the following to initiate the download:
Step
Command
1
RedBoot> load -r -v -m {
xmodem | ymodem } -b
base_address
5
RedBoot> fis delete -n 1
6
RedBoot> fis create
7
RedBoot> fis list -l
8
RedBoot> go
Note
This type of download takes about 25 minutes since it uses a serial link at
only 9600 bps.

Additional information

For detailed information about configuring and operating guidance, set up procedures, and troubleshooting,
refer to the Software Configuration Guide on the enclosed CD-ROM or the Patton website at
www.patton.com. On the CD you will also find a freeware TFTP server, which is also available from the
www.solarwinds.net
web site.

Additional information

4 • Getting started with the SmartNode 4400 Series
Downloads an application image into the volatile memory
(RAM) from where the SmartNode could directly execute it.
'xmodem' or 'ymodem': Specify the protocol to be used, X-
Modem or Y-Modem
base_address: memory location where to store the application
image. Use the default address 0x1800100
Execute the above RedBoot command first, then start the trans-
fer from the terminal program with the command 'Send file via
X-Modem' (or similar).
Deletes the first application image.
Reply with 'y' to the confirmation request.
Stores the downloaded application image to the permanent
memory (flash:).
Reply with 'y' to the confirmation request.
Checks whether the image has been successfully stored,
whether it is the desired Release and Build, and whether it is
valid.
Starts the application image that was downloaded to the vola-
tile memory (RAM).
Purpose
44
