SmartNode 4400 Series Getting Started Guide

Connecting cables

This section describes installing the interface, power, and ground cables in the following order:
CAUTION
1. Installing the RJ-11 voice port (FXS) cable or cables (see section
2. Installing the 10/100 Ethernet port cable (see section
3. Installing the RS-232 console cable (see section
(DCE configured)"
4. Installing the power input (see section
WARNING

Connecting the FXS ports

The remote FXO devices are connected to the IpChannel Bank via the RJ-21X cable. Consult
page 57 in order to connect the FXO devices to the selected FXS port on the IpChannel Bank.
1. Connect the RJ-21X connector of the cable into the 64-pin or 50-pin RJ-21X receptacle on the IpChannel
Bank. The pin count will depend on the IpChannel Bank that you ordered.
2. The other end of the cable has 25 non-terminated twisted-pairs for connection to punch-down blocks.
Select the twisted-pairs which will be used for
3. Select and attach the appropriate twisted-pair from each FXO device on punch-down blocks for connec-
tion to the chosen port on the IpChannel Bank.

Connecting the Ethernet ports

The IpChannel Bank has dual 10/100 Ethernet interfaces. One is for the WAN connection. The other is for
connecting to your Ethernet LAN. The Ethernet ports will auto-sense the correct speed of the local LAN and
automatically negotiate to half- or full-duplex operation. This section describes connecting the IpChannel
Bank to the Ethernet LAN via an Ethernet hub or switch.
Installing the IpChannel Bank
The cables must be acceptable for external use
Interconnecting
and must be rated for the proper application with respect to volt-
age, current, anticipated temperature, flammability, and
mechanical serviceability.
on page 31)
"Connecting power"
Do not work on the system or connect or disconnect cables during periods of
lightning activity.

"Connecting the FXS ports"

"Connecting the Ethernet ports"

"Connecting the EIA-561 RS-232 configuration port
on page 31)
3 • Hardware installation
on page 29)
on page 29)
Appendix C on
