V-Panel™ Integrated 12" & 15" Touch Screens
4 • V-Panel™ Integrated 12" & 15" Touch Screens: TPMC-V12 & TPMC-V15
Remote Annotation
Remote annotation capability allows multiple touch screen users to draw with their
fingertips over the same video image or whiteboard screen, enabling enhanced
interaction between several participants in a courtroom, classroom or council
chamber.
Streamlined, Flexible Connectivity
Each TPMC-V12/15 model ships with a compact interface module
1
(TPMC-V-IMCW ), which may be discreetly mounted in a 1-gang electrical box,
equipment rack or any flat surface, providing a single point of connectivity for
power, communications and video signals. Connection between the touch screen and
interface module can be made using a V-Cable Siamese Cable (TPMC-V-CBL-S
providing a very clean appearance with lengths available up to 15 feet (4.5 meters).
For longer distances up to 330 feet (100 meters), especially for in-wall applications,
you may use a choice of several Crestron wire solutions or generic CAT5e cable.
The TPMC-V-IMCW interface module provides both Cresnet
Ethernet ports for control system communications and LAN access. Power can be
furnished via Cresnet or an optional power pack (PW-2420RU, sold separately).
Wired video connectivity is handled through a single balanced or unbalanced
composite input, allowing compatibility with both conventional coaxial and Crestron
®
Home Balanced AV distribution systems.
The TPMC-V12/15 can also be installed without using the interface module.
Connectors on the touch screen allow for direct connection to Ethernet or Cresnet,
with power provided via the Cresnet port.
NOTE: Wired video connectivity is only available through the TPMC-V-IMCW
interface module.
1. Item included; refer to individual product specifications for additional information.
2. The TPMC-V12/15 models include (1) TPMC-V-CBL-S3 3 foot (0.9 meter) Siamese Cable.
The TPMC-V12/15-TILT models include (1) TPMC-V-CBL-S6 6 foot (1.8 meter) Siamese Cable.
The TPMC-V12/15-WALL models do not include any cable.
3. For wiring between the TPMC-V12 and interface module, use a TPMC-V-CBL-S Siamese Cable,
®
CresCAT , CresCAT-D-HP, CresCAT-QM, DM-CBL or quality CAT5e/CAT6. CAT5e/6 requires an
additional CRESNET or CRESNET-HP for Cresnet and power or else a single wire pair for power
only. The maximum length for CRESCAT-D-HP, CAT5e/6 + CRESNET-HP or CAT5e/6 + 14 AWG
power wire is 330 feet (100 meters) minus the length of any Ethernet cable connected to the LAN jack
on the rear of the interface module. The maximum length for CresCAT, CresCAT-QM, DM-CBL,
CAT5e/6 + CRESNET or CAT5e/6 + 18 AWG power wire is 155 feet (47 meters) minus the length of
any additional Ethernet cable beyond 175 feet (53 meters).
4. For wiring between the TPMC-V15 and interface module, use a TPMC-V-CBL-S Siamese Cable,
CresCAT, CresCAT-D-HP, CresCAT-QM, DM-CBL or quality CAT5e/CAT6. CAT5e/6 requires an
additional CRESNET or CRESNET-HP for Cresnet and power or else a single wire pair for power
only. The maximum length for CRESCAT-D-HP, CAT5e/6 + CRESNET-HP or CAT5e/6 + 14 AWG
power wire is 330 feet (100 meters) minus the length of any Ethernet cable connected to the LAN jack
on the rear of the interface module. The maximum length for CresCAT, CresCAT-QM, DM-CBL,
CAT5e/6 + CRESNET or CAT5e/6 + 18 AWG power wire is 148 feet (45 meters) minus the length of
any additional Ethernet cable beyond 182 feet (55 meters).
