- Page 1 PU-8H8CTXIR 8-Way HDMI HDBaseT™ Transmitter with 8x8 IR Matrix (inc. POE) OPERATION MANUAL...
- Page 2 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. -
Page 4: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ..........1 3. Package Contents ........1 4. System Requirements ......1 5. Features ............ 2 6. Operation Controls and Functions ..3 6.1 Transmitter’s Front Panel ....3 6.2 Transmitter’s Rear Panel ....4 7. -
Page 5: Introduction
1. INTRODUCTION The HDMI over CAT6 transmitter with IR Matrix is an outstanding device for extending and controlling your HDMI signal. With 8 HDMI input ports and 8 CAT6 output ports this device allows a great amount of sources and display to be controlled and display up to 100 meters away. -
Page 6: Features
5. FEATURES • HDMI, HDCP1.1 and DVI compliant • Supports HDMI v1.4 features: • 3D • Supports Stereo audio input and output, analog and digital audio signal • Supports high bit rate audio up to 192kHz • Supports resolutions to VGA ~ WUXGA and 480i~1080p follow by output display’s EDID •... -
Page 7: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Transmitter’s Front Panel 2 3 4 5 6 LCM: This monitor displays your setting information of each IR’s input and output selection. This IR window accepts the remote control signal of this device and all the source and display equipment’s IR signal. Power button and LED: Press this button to turn on the device or press it again to set it to standby mode. -
Page 8: Transmitter's Rear Panel
6.2 Transmitter’s Rear Panel RS-232 AUX: This slot is to connect with D-Sub 9pin cable from the third device for RS-232 signal sending and controlling. RS-232 MAIN: This slot is to connect with D-Sub 9pin cable from PC/NB for RS-232 signal sending to the device and the third device. -
Page 9: Remote Control
MAIN 5V: This slot is to plug the power adaptor included in the package and then connect to the AC wall outlet for power supply. POE / 24V: This slot is where user connect the 24V DC power adaptor and plug the adaptor to an AC wall outlet for power supply when the CAT 6 out are not connected with power supply. - Page 10 Discrete IR codes for 8x8 IR matrix (IR3) Select / input 1 input 2 input 3 input 4 input 5 input 6 input 7 input 8 Dipswitch output A 0cx88 0x89 0x8A 0x8C 0x8D 0x8E 0x90 0x91 ↓↓↓↓ output B 0x88 0x89 0x8A...
-
Page 11: Ir Pin Assignment
8. IR PIN ASSIGNMENT IR Blaster IR Extender IR Blaster IR Receiver ① IR signal ① Power 5V ② Power 5V ② NC ③ Grounding ③ IR blaster signal ① ② ③ ① ③ ② IR Function OUT(TV) IN(DVD) DVD1 有信... -
Page 12: Rs-232 Protocols
TVA 有信號 時 TVB 有信號 時 TVC 有信 號時 TVD 有信 號時 TVE 有信號 時 TVF 有信號 時 TVG 有信 號時 TVH 有信 號時 9. RS-232 PROTOCOLS 9.1Pin Assignment CSI-8H8CV2IR Remote Control Console Assignment Assignment... -
Page 13: Rs-232 Commands
Baud Rate: 9600bps Data bit: 8 bits Parity: None Flow Control: None 9.2 RS-232 Commands COMMAND ACTION COMMAND ACTION Power Off POWER 00 (standby) POWER 01 Power On OUTPUT A SELECT OUTPUT B SELECT PORT 11 PORT 21 INPUT1 INPUT1 OUTPUT A SELECT OUTPUT B SELECT PORT 12... - Page 14 OUTPUT C SELECT OUTPUT D SELECT PORT 34 PORT 44 INPUT4 INPUT4 OUTPUT C SELECT OUTPUT D SELECT PORT 35 PORT 45 INPUT5 INPUT5 OUTPUT C SELECT OUTPUT D SELECT PORT 36 PORT 46 INPUT6 INPUT6 OUTPUT C SELECT OUTPUT D SELECT PORT 37 PORT 47 INPUT7...
-
Page 15: Specifications
OUTPUT G SELECT OUTPUT H SELECT PORT 76 PORT 86 INPUT6 INPUT6 OUTPUT G SELECT OUTPUT H SELECT PORT 77 PORT 87 INPUT7 INPUT7 OUTPUT G SELECT OUTPUT H SELECT PORT 78 PORT 88 INPUT8 INPUT8 10. SPECIFICATIONS Maximum Data Rate 6.75 Gbps (2.25 Gbps per clock) Maximum Pixel Rate 225 MHz... -
Page 16: Connection And Installation
11. CONNECTION AND INSTALLATION RS-232 Command CH-1109RXC CAT-6 100m CH-1109RXC CH-1109RXC CH-1109RXC RS-232 Command... - Page 17 ° ° RS-232 Command CSI-8H8CV2IR CMLUX-88S HDMI Cable RS-232 Command RS-232 Cable...
-
Page 18: Acronyms
12. ACRONYMS ACRONYM COMPLETE TERM Digital Theater System Digital Visual Interface EDID Extended Display Identification Data HDCP High-bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface HDTV High-Definition Television Liquid Crystal Monitor Universal Serial Bus UXGA Ultra Extended Graphics Array Video Graphics Array... - Page 20 www.cypeurope.com...
