- Page 1 ® PUV-3000TX UHD+ HDMI over HDBaseT 3.0 Transmitter (18Gbps, 4K@60Hz 4:4:4, 8-bit) OPERATION MANUAL...
- Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. CYP (UK) Ltd assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be contained in this document.
- Page 4 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
-
Page 5: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ..........1 3. Package Contents .........1 4. System Requirements ........1 5. Features ............2 6. Operation Controls and Functions ....3 6.1 Front Panel ............3 6.2 Rear Panel ...............4 6.3 IR Cable Pinouts ...........5 6.4 Serial Pinout ............5 7. -
Page 6: Introduction
1. INTRODUCTION This 4K UHD HDMI over HDBaseT transmitter uses HDBaseT 3.0, the newest generation of HDBaseT technology, and when combined with a compatible receiver is the perfect solution for extending full bandwidth (18Gbps) HDMI 2.0, 4K@60Hz (4:4:4, 8-bit) video with HD audio via a single run of Cat.6A/7 cable over distances of up to 40 meters. -
Page 7: Features
5. FEATURES HDMI 2.0 and DVI 1.0 compatible HDCP 2.2 and HDCP 1.x compliant HDBaseT 3.0 compliant (Backwards compatible with HDBaseT 2.0/1.0) 1 HDMI input, 1 HDMI output, and 1 HDBaseT output Supports up to 4K UHD (18Gbps, 4K@60Hz 4:4:4, 8-bit) video input and output over both HDMI and HDBaseT Supports Deep input and output up to 12-bit... -
Page 8: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel PUV-3000TX HDMI over HDBaseT R PWR Transmitter LINK RS-232 4-pin Terminal Block: Connect to a PC, laptop, or serial controllable device with a 4-pin adapter cable for the extension of RS-232 signals between both ends of the HDBaseT connection. -
Page 9: Rear Panel
6.2 Rear Panel DC 24V CAT6A/7 OUT HDMI IN HDMI OUT DC 24V Port: Plug the 24V DC power adapter into this port and connect it to an AC wall outlet for power. USB Port (Micro-B): This port is reserved for firmware update use only. -
Page 10: Ir Cable Pinouts
6.3 IR Cable Pinouts IR Blaster + IR Extender 4-pin Terminal Block 3.3V 6.4 Serial Pinout 4-pin Terminal Block... -
Page 11: Connection Diagram
7. CONNECTION DIAGRAM Tower PC Local Monitor 60° 1.5m 60° RS-232 IR Input & Output HDMI Input HDMI Output PUV-3000TX HDMI over HDBaseT R PWR Transmitter LINK Power Supply DC 24V CAT6A/7 OUT HDMI IN HDMI OUT IR Input & PUV-3000RX... -
Page 12: Specifications
8. SPECIFICATIONS 8.1 Technical Specifications HDMI Bandwidth 18Gbps HDBaseT Bandwidth 18Gbps Input Ports 1×HDMI (Type-A) Output Ports 1×HDBaseT (RJ-45) 1×HDMI (Type-A) Pass-through Ports 1×IR In/Out (4-pin Terminal Block) 1×RS-232 (4-pin Terminal Block) Pass-through/Service Port 1×USB 2.0 (Micro-B) IR Frequency 30 ~ 50kHz (30 ~ 60kHz under ideal conditions) Baud Rate Up to 115200... -
Page 13: Video Specifications
8.2 Video Specifications Input Output Supported Resolutions (Hz) HDMI HDMI HDBT 720×400p@70/85 640×480p@60/72/75/85 720×480i@60 720×480p@60 720×576i@50 720×576p@50 800×600p@56/60/72/75/85 848×480p@60 ... - Page 14 Input Output Supported Resolutions (Hz) HDMI HDMI HDBT 1920×1080p@24/25/30 1920×1080p@50/60 1920×1200p@60RB 2560×1440p@60RB 2560×1600p@60RB 2048×1080p@24/25/30 2048×1080p@50/60 3840×2160p@24/25/30 3840×2160p@50/60 (4:2:0) ...
-
Page 15: Audio Specifications
8.3 Audio Specifications 8.3.1 Digital Audio HDMI Input / Output & HDBaseT Output LPCM Max Channels 8 Channels Sampling Rate (kHz) 32, 44.1, 48, 88.2, 96, 176.4, 192 Bitstream Supported Formats Standard & High-Definition 8.4 Cable Specifications 1080p 4K30 4K60 (4:4:4) (4:4:4) Cable Length... -
Page 16: Hdbaset Features
8.5 HDBaseT Features HDBaseT Feature Set Transmitter Video & Audio Extension Supported LAN Extension Unsupported Send power to Receiver Supported (PoH) Accept power from Receiver Unsupported IR Extension Supported RS-232 Extension Supported USB 2.0 Extension Unsupported... -
Page 17: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM 4K UHD 4K Ultra-High-Definition (10.2Gbps max) 4K UHD 4K Ultra-High-Definition (18Gbps max) AVoIP Audio/Video over IP Cat.5e Enhanced Category 5 cable Cat.6 Category 6 cable Cat.6A Augmented Category 6 cable Cat.7 Category 7 cable Digital Visual Interface EDID Extended Display Identification Data Gigabit Ethernet... - Page 18 ACRONYM COMPLETE TERM Universal Serial Bus Video Graphics Array WUXGA (RB) Widescreen Ultra Extended Graphics Array (Reduced Blanking) Extended Graphics Array...
- Page 20 CYP (UK) Ltd., Unit 7, Shepperton Business Park, Govett Avenue, Shepperton, Middlesex, TW17 Tel: +44 (0) 20 3137 9180 | Fax: +44 (0) 20 3137 6279 Email: sales@cypeurope.com www.cypeurope.com v1.00...
