HP Server rx2600 Installation Manual page 25

Table 1-3
Graphics Card
NVIDIA Quadro4
900XGL
1. Only common resolutions are listed. Other intermediate resolutions are possible.
2.
The maximum frequency may not be available at all color depths.
Table 1-4
NVIDIA Quadro4
900XGL
Chapter 1
Resolutions and Frequencies for the NVIDIA Quadro4 900 XGL
(Analog Monitors with DB-15 Connector; Linux)
Display
1
Resolution
640×480
800×600
1024×768
1152×864
1280×960
1280×1024
1600×900
1600×1200
1920×1080
1920×1200
2048×1536
Resolutions and Frequencies for the NVIDIA Quadro4 900 XGL
(Digital Monitors with DVI Connector; Linux)
Graphics Card
1. Only common resolutions are listed. Other intermediate resolutions are
possible.
Select a Monitor for your Graphics Card
Vertical Frequency (Hz)
60, 70, 72, 75, 85, 100, 120, 140, 144, 150, 170, 200, 240
60, 70, 72, 75, 85, 100, 120, 140, 144, 150, 170, 200, 240
60, 70, 72, 75, 85, 100, 120, 140, 144, 150, 170, 200, 240
60, 70, 72, 75, 85, 100, 120, 140, 144, 150, 170, 200
60, 70, 72, 75, 85, 100, 120, 140, 144, 150, 170
60, 70, 72, 75, 85, 100, 120, 140, 144, 150
60, 70, 72, 75, 85, 100, 120, 140, 144, 150
60, 70, 72, 75, 85, 100, 120
60, 70, 72, 75, 85, 100
60, 70, 72, 75, 85, 100
60, 70, 72, 75
Display
1
Resolution
640×480 60
800×600 60
1024×768 60
1152×864 60
1280×960 60
1280×1024 60
1600×900 60
1600×1200 60
Setting Up and Using Your System
2
Vertical Frequency (Hz)
25
