Setting Up and Using Your System

Select a Monitor for your Graphics Card

CAUTION
Table 1-2
Graphics Card
NVIDIA Quadro2 EX
1. Only common resolutions are listed. Other intermediate resolutions are possible.
2. The maximum frequency may not be available at all color depths.
24
Select a Monitor for your Graphics Card
This section provides a list of display resolutions and frequencies for the
graphics cards supported by your system. By using these resolutions and
frequencies you will be able to select the appropriate monitor for your
graphics card. Note that frequencies of 85Hz and higher provide
ergonomic, flicker-free viewing.
If the monitor you select is DDC-2B or DDC-2B+ compliant, the graphics
card will automatically limit itself to those resolutions and frequencies
supported by that monitor. In this case, you do not need to use the tables
in this section to select your monitor.
To prevent possible damage to your monitor, make certain you select a
monitor that supports the resolutions and frequencies you wish to use.
Resolutions and Frequencies for the NVIDIA Quadro2 EX
(Analog Monitors and DB-15 Connector; Linux)
Display
1
Resolution
640×480
800×600
1024×768
1280×1024
1600×1200
1920×1200
2048×1536
Vertical Frequency (Hz)
60, 70, 72, 75, 85, 100, 120, 140, 144, 150, 170, 200, 240
60, 70, 72, 75, 85, 100, 120, 140, 144, 150, 170, 200, 240
60, 70, 72, 75, 85, 100, 120, 140, 144, 150, 170, 200, 240
60, 70, 72, 75, 85, 100, 120, 140, 144, 150, 170
60, 70, 72, 75, 85, 100, 120
60, 70, 72, 75, 85, 100
60, 70, 72, 75
2
Chapter 1
