Master Image MI-WAVE3D Installation & Operation Manual page 40

LOG
# POWER ON : v1.0.0
RUNNING
STOP
2D
2D MOVING
3D
Status 3D MOVING
STOP MOVING
FREQ : 72.0Hz
SYNC PULSE : 3D
GPIO 15-9 : 3D
GPIO 37-9 : 3D
AUTO COMMAND : RUN
3D POSITION : LEFT
SYNC SOURCE : GPIO
AUTOMATION : GPIO(37-9)
REFERENCE(1) : 72Hz
REFERENCE(1) : 72Hz ON
REFERENCE(1) : 72Hz OFF
POLARITY : TRUE
PASSWORD : CHANGED
Setting IP : 192.168.10.95
GW : 192.168.10.1
MASK : 255.255.255.0
FACTORY RESET
DELAY 2D : 5
HOST NAME : MI-WAVE3D
MAC : 00-00-00-00-00-00
POLARITY(SW) : TRUE
3D POSITION(SW) : LEFT
ERR : ACT NOT DETECT
ERR : ACT NOT LIMIT
Error
ERR : ACT FAULT
ERR : FAN ERROR
Installation & Operation Manual | MI-WAVE3D
Description
Power On : Firmware Version Number
RUNNING
STOP
Current Position : 2D
Actuator Moving to 2D Position
Current Position : 3D
Actuator Moving to 3D Position
Actuator Stop
Sync Change
SYNC PULSE Input [2D/3D]
GPIO 15-9 Input [2D/3D]
GPIO 37-9 Input [2D/3D/RUN]
AUTOMATION COMMAND [2D/3D/RUN/STOP]
ACTUATOR 3D Position Setting
Sync Source Setting
Automation Source Setting
Reference Sync Frequency Setting
Reference Sync Frequency Enabled
Reference Sync Frequency Disabled
Sync Polarity Setting
Password Changed
Ethernet IP Setting
Ethernet Gateway Setting
Ethernet Subnet Mask Setting
Factory Reset
Delay 2D Time Setting
SYSTEM NAME Setting
MAC-ADDRESS Setting
POLARITY Mode Switch Setting
3D POSITION Mode Switch Setting
No Connection with the Actuator
No Movement of the Actuator Normally
Malfunction Status of the Actuator
No Operation of the Cooling Fan
© MASTERIMAGE 3D, Inc. 40
