Installation & Operation Manual | MI-WAVE3D
5.2.
Actuator
Stroke: 300mm
Mounting Plate for LC P
olarization Modulator
Robot Chain
Power Adaptor
Jack
Sync Cable
USB Connector
(for F/W Download)
2D
GPIO Sync Cable
Connector
DC Power Adaptor
Connector
3D
Actuator
Connector
(for Test Jig)
LC Polarization Modulator installed
on the Actuator
© MASTERIMAGE 3D, Inc.
13
