Installation & Operation Manual | MI-WAVE3D
5. Detailed Component Overview
5.1.
Liquid Crystal Polarization Modulator (LCPM)
LC Frame
Liquid Crystal Panel
3-Digit LED
RUN/STOP Button
Cooling Fan
Stand :
Used to adjust the height and an
gle of the LC Frame
in respect to the projector lens.
Mode
Selector
Cool Fan
Power Adaptor
Sync Cable
Ethernet Connector
Connector
Jack
Connector
Actuator Cable
(DC 24V/2.5A)
Connector
© MASTERIMAGE 3D, Inc.
12
