Equipment Overview

1. IsatDock DRIVE unit
2. Key Lock
3. IsatPhone Eject Button
4. IsatPhone Pro
5. IsatPhone Pro Docking Tray
6. Function Buttons
7. Status Indication Light
8. Power Cable Loom
a. Power Supply
b. Satellite TNC-Female Connector
c. GPS SMA-Female Connector
d. Microphone
e. Speaker
f. Alert Loop (green & brown)
Horn Alert (blue)
Radio Mute (white)
9. RAM Mounting
10. Privacy Handset Connection
11. Micro USB Data Connection*
* Data services scheduled to be available Q1 2011.
Firmware upgrade will be required
2
3
4
5
6
7
IsatDock DRIVE - Installation & User Manual
1
8
9
10
11
a
b
c
d
e
f
13
